VTH5123H-W-S2 video intercom system
17.8 cm (7") White
Model VTH5123H-W-S2EAN 6939554946219
30 specifications
- Display17.8 cm (7")
- Resolution1024 x 600 pixels
- ConnectivityWired
- Weight633 g
- ColourWhite
- Built-in speaker(s)Yes
Overview
- Display
- 17.8 cm (7")
- Resolution
- 1024 x 600 pixels
- Connectivity
- Wired
- Weight
- 633 g
- Colour
- White
- Built-in speaker(s)
- Yes
- Brand
- Dahua Technology
- Category
- Video Intercom System
- Model
- VTH5123H-W-S2
- Part number
- VTH5123H-W-S2
- EAN / UPC
- 6939554946219
- Also known as
- Dahua Technology VTH5123H-W-S2 video intercom system 17.8 cm (7") White
Specifications
30 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Number of displays supported | 1 |
| Speakerphone | Yes |
| Frequency band | 2.4 GHz |
Display
| Specification | Value |
|---|---|
| Display diagonal | 17.8 cm (7") |
| Display technology | TFT |
| Display resolution | 1024 x 600 pixels |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Voice codecs | G.711a, G.711u, PCM |
Design
| Specification | Value |
|---|---|
| Product colour | White |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
Storage
| Specification | Value |
|---|---|
| Memory card included | MicroSD |
| Included memory card size | 64 GB |
Outdoor unit
| Specification | Value |
|---|---|
| Alarm input channels (transmitter) | 6 |
| RS-485 ports (transmitter) | 1 |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Supported network protocols | IPv4; UDP; DNS; TCP |
Power
| Specification | Value |
|---|---|
| Power consumption (standby) | 2.5 W |
| Power consumption (max) | 10 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 130 mm |
| Depth | 23.9 mm |
| Height | 189 mm |
| Weight | 633 g |
