KTP05(S) video intercom system
2 MP 17.8 cm (7") Black, White
Model KTP05(S)Part no. DHI-KTP05(S)
33 specifications
- Display17.8 cm (7")
- Resolution1024 x 600 pixels
- ConnectivityWired & Wireless
- OSEmbedded LINUX
- ColourYes
- Megapixel (approx.)2 MP
Overview
- Display
- 17.8 cm (7")
- Resolution
- 1024 x 600 pixels
- Connectivity
- Wired & Wireless
- OS
- Embedded LINUX
- Colour
- Yes
- Megapixel (approx.)
- 2 MP
- Brand
- Dahua Technology
- Category
- Video Intercom System
- Model
- KTP05(S)
- Part number
- DHI-KTP05(S)
- Also known as
- Dahua Technology KTP05(S) video intercom system 2 MP 17.8 cm (7") Black, White
Specifications
33 specifications in 11 groups
Features
| Specification | Value |
|---|---|
| Connectivity technology | Wired & Wireless |
| Colour | Yes |
| Built-in microphone | Yes |
| Frequency band | 2.4 GHz |
Display
| Specification | Value |
|---|---|
| Display diagonal | 17.8 cm (7") |
| Display technology | TFT |
| Display resolution | 1024 x 600 pixels |
| Video formats supported | H.264 |
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 2 MP |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
| Viewing angle, diagonal | 158° |
| Viewing angle, horizontal | 138° |
| Viewing angle, vertical | 78° |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
| Voice codecs | G.711a, G.711u, PCM |
Design
| Specification | Value |
|---|---|
| Product colour | Black, White |
| Control type | Buttons |
| Housing material | Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC) |
Indoor unit
| Specification | Value |
|---|---|
| RS-485 ports | 1 |
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | DNS;RTSP;SSH;SIP;RTP |
Software
| Specification | Value |
|---|---|
| Operating system installed | Embedded LINUX |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 6 W |
| Power consumption (standby) | 2 W |
Packaging data
| Specification | Value |
|---|---|
| Indoor unit included | Yes |
| Outdoor unit included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
