DHI-KTP03 video intercom system
1 MP 17.8 cm (7") Black
Model DHI-KTP03
38 specifications
- Display17.8 cm (7")
- Resolution1024 x 600 pixels
- Memory128 MB
- ConnectivityWired
- OSEmbedded LINUX
- Weight560 g
Overview
- Display
- 17.8 cm (7")
- Resolution
- 1024 x 600 pixels
- Memory
- 128 MB
- Connectivity
- Wired
- OS
- Embedded LINUX
- Weight
- 560 g
- Brand
- Dahua Technology
- Category
- Video Intercom System
- Model
- DHI-KTP03
- Part number
- DHI-KTP03
- Also known as
- Dahua Technology DHI-KTP03 video intercom system 1 MP 17.8 cm (7") Black
Specifications
38 specifications in 14 groups
Features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Colour | Yes |
Display
| Specification | Value |
|---|---|
| Display diagonal | 17.8 cm (7") |
| Display technology | TFT |
| Display resolution | 1024 x 600 pixels |
| Wide Dynamic Range (WDR) | Yes |
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 1 MP |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Fixed focal length | 2 mm |
| Viewing angle, diagonal | 122° |
| Viewing angle, horizontal | 107° |
| Viewing angle, vertical | 61° |
Audio
| Specification | Value |
|---|---|
| Built-in speaker(s) | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | SECC |
Storage
| Specification | Value |
|---|---|
| Memory card slot | Yes |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 64 GB |
Indoor unit
| Specification | Value |
|---|---|
| Flash memory | 128 MB |
| Internal memory | 128 MB |
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 6 |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
Software
| Specification | Value |
|---|---|
| Operating system installed | Embedded LINUX |
Power
| Specification | Value |
|---|---|
| Indoor unit power type | AC |
| AC adapter input voltage | 100 - 240 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -30 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 194 mm |
| Depth | 108.1 mm |
| Height | 35 mm |
| Weight | 560 g |
Packaging data
| Specification | Value |
|---|---|
| Indoor unit included | Yes |
| Outdoor unit included | Yes |
| Package weight | 1.11 kg |
Technical details
| Specification | Value |
|---|---|
| Certification | CE; FCC; UL |
