UVC86
Model UVC86Part no. 1206662EAN 6938818318021
48 specifications
- Weight3.27 kg
- ColourBlack
- Megapixel (approx.)8 MP
- Maximum video resolution3840 x 2160 pixels
- HDMI ports quantity1
- Power source typeAC
Overview
- Weight
- 3.27 kg
- Colour
- Black
- Megapixel (approx.)
- 8 MP
- Maximum video resolution
- 3840 x 2160 pixels
- HDMI ports quantity
- 1
- Power source type
- AC
- Brand
- Yealink
- Category
- Video Conferencing Camera
- Model
- UVC86
- Part numbers
- 1206662, 1206619
- EAN / UPC
- 6938818318021, 841885107534, 841885108463, 5715328290808 +3 more
- Also known as
- Yealink UVC86
Specifications
48 specifications in 11 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 8 MP |
| Camera type | Dual camera |
| Second camera resolution | 8 MP |
| Zoom capability | Yes |
| Optical zoom | 12x |
| Digital zoom | 1.7x |
| Horizontal field of view | 110° |
| Vertical field of view | 78° |
| Number of camera presets | 9 |
| PTZ control | Yes |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 30 fps |
| HD type | 4K Ultra HD |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Mounting type | Stand |
| Tilt angle range | -90 - 40° |
| Pan range | -100 - 100° |
| Country of origin | China |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input frequency | 100 - 240 Hz |
| DC input voltage | 48 V |
| Input current | 0.7 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95% |
Performance
| Specification | Value |
|---|---|
| Auto framing | Yes |
| Auto-tracking | Yes |
| Tracking modes | Presenter mode |
| Cable lock slot | Yes |
Packaging content
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Remote control included | Yes |
| Cables included | USB |
| USB cable length | 7 m |
| AC adapter included | Yes |
| Packaging content | VC86 Camera VCR20 Remote Control Power Adapter Wall Bracket and Accessories 7m USB Cable (2.5m for MVC bundle) |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85258900 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 210 mm |
| Depth | 156 mm |
| Height | 156 mm |
| Weight | 3.27 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 210 mm |
| Package depth | 183 mm |
| Package height | 156 mm |
| Package weight | 4.54 kg |
