TR535 8 MP Black 3840 x 2160 pixels 60 fps Exmor CMOS 25.4 / 2.8 mm (1 / 2.8")
AVer

TR535 8 MP Black 3840 x 2160 pixels 60 fps Exmor CMOS 25.4 / 2.8 mm (1 / 2.8")

Model TR535Part no. 61S9330000ACEAN 4719552128044

107 specifications
  • Weight3.6 kg
  • ColourBlack
  • Megapixel (approx.)8 MP
  • Maximum video resolution3840 x 2160 pixels
  • HDMI ports quantity2
  • Power source typeDC, PoE
See all specifications

Overview

Weight
3.6 kg
Colour
Black
Megapixel (approx.)
8 MP
Maximum video resolution
3840 x 2160 pixels
HDMI ports quantity
2
Power source type
DC, PoE
Brand
AVer
Model
TR535
Part numbers
61S9330000AC, 61S9330000AN
EAN / UPC
4719552128044
Also known as
AVer TR535 8 MP Black 3840 x 2160 pixels 60 fps Exmor CMOS 25.4 / 2.8 mm (1 / 2.8")

Specifications

107 specifications in 16 groups

Camera

Megapixel (approx.)8 MP
Camera typeDual camera
Second camera resolution8 MP
Sensor typeExmor CMOS
Optical sensor size25.4 / 2.8 mm (1 / 2.8")
Zoom capabilityYes
Optical zoom30x
Digital zoom1x
Combined zoom30x
Field of view (tele)2.8°
Field of view (wide)69.2°
Focal length range4.5 - 135 mm
Second camera field of view (FOV) angle113°
Horizontal field of view (tele)2.5°
Horizontal field of view (wide)62.3°
Vertical field of view (tele)1.4°
Vertical field of view (wide)37.3°
Minimum illumination0.5 lx
Signal-to-Noise Ratio (SNR)50 dB
Flip & mirrorYes
Second camera F-number2.22
Aperture range (F-F)1.8 - 4.7
White balanceATW, Auto, Indoor, Manual, One push, Outdoor
Auto exposureYes
Light exposure modesAperture priority AE, Shutter priority AE, IRIS priority AE
Closest focusing distance0.1 m
Second camera lens typeWide-angle
Wide Dynamic Range (WDR)Yes
Back Light Compensation (BLC)Yes
Gain control typeAuto/Manual
PTZ controlYes
PTZ protocolsCGI, ONVIF, Pelco-P/D, UAC, UVC, VISCA
3D NR (Noise Reduction)Yes
Face trackingYes
Fastest camera shutter speed1/10000 s
Slowest camera shutter speed1 s
Voice trackingYes

Video

Maximum video resolution3840 x 2160 pixels
Maximum frame rate60 fps
HD type4K Ultra HD
Resolution at capture speed1280x720@50fps, 1280x720@60fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@25fps, 3840x2160@30fps, 3840x2160@60fps
Video formats supportedH.264, H.265, M-JPEG
Number of TV lines1600

Design

Product colourBlack
Tilt angle range-30 - 90°
Pan range-170 - 170°
LED indicatorsPower
Tally lightYes
Web-based managementYes
Tilt preset speed200 °/sec
Tilt speed (max)100 °/sec
Tilt speed (min)0.1 °/sec
Pan preset speed200 °/sec
Pan speed (max)100 °/sec
Pan speed (min)0.1 °/sec
Country of originTaiwan

Ports & interfaces

HDMI ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity1
RS-232 ports1
RS-422 ports1
DC-in jackYes
3G-SDI outputYes
Microphone inYes
Line-inYes

Power

Power source typeDC, PoE
AC input frequency50/60 Hz
AC input voltage100 - 240 V
DC input voltage12 V
Input current5 A

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)20 - 95%

System requirements

Windows operating systems supportedWindows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Mac operating systems supportedMac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma
Mobile operating systems supportediOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 13.4, iOS 14, iOS 14.5, iOS 15, iOS 16, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3, iPadOS, iPadOS 13, iPadOS 14, iPadOS 17.1.1, iPadOS 17.4, iPadOS 17.5

Performance

Live video previewYes
Auto-trackingYes
Tracking modesPresenter mode, Zone mode
Remote control functionYes
Remote control typeIR
Cable lock slotYes
Cable lock slot typeKensington

Audio

Built-in speaker(s)Yes
Audio codecsAAC-LC (48K)
Supported sample rates48 kHz

Network

Ethernet LAN data rates10,100,1000,2500 Mbit/s
Streaming capabilityYes
Network streamingYes
Bit rate controlConstant Bit Rate (CBR), Variable Bit Rate (VBR)
Bit rate range512 - 64000 Kbit/s
Supported network protocolsIPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP

Packaging content

Remote control includedYes
Packaging contentCamera, Remote Control, RS-232 In/Out Cable, Din 8 To D-Sub 9 Cable, Power Adapter, Power Cord, Cable Tie (x7), M2 x 4 mm Screw (x5), M3 x 6 mm Screw (x3), 1/4"-20L 6.5mm Screw (x2), Cable Fixing Plate (x2), Ceiling Mount Bracket (x2), Drilling Paper, Quick Start Guide

Certificates

Compliance certificatesCE, Federal Communications Commission (FCC), RoHS

Logistics data

Harmonized System (HS) code8525801990
Products per master (outer) case1 pc(s)
Products per pallet42 pc(s)

Technical details

Warranty period5 year(s)

Weight & dimensions

Width202.5 mm
Depth218.5 mm
Height250.7 mm
Weight3.6 kg

Packaging data

Package width389 mm
Package depth278 mm
Package height310 mm
Package weight6.6 kg
