RoboSHOT 30E-M
Model RoboSHOT 30E-MPart no. 999-21132-001EAN 840077508128
38 specifications
- Weight2.2 kg
- ColourBlack
- Megapixel (approx.)8.51 MP
- Maximum video resolution1920 x 1080 pixels
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity1
- Power source typePoE
Overview
- Weight
- 2.2 kg
- Colour
- Black
- Megapixel (approx.)
- 8.51 MP
- Maximum video resolution
- 1920 x 1080 pixels
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
- 1
- Power source type
- PoE
- Brand
- Vaddio
- Category
- Video Conferencing Camera
- Model
- RoboSHOT 30E-M
- Part numbers
- 999-21132-001, 999-21132-001W
- EAN / UPC
- 840077508128, 840077508166
- Also known as
- Vaddio RoboSHOT 30E-M HD PTZ Camera
Specifications
38 specifications in 11 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 8.51 MP |
| Camera type | Single camera |
| Sensor type | Exmor |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Zoom capability | Yes |
| Field of view (tele) | 31.2° |
| Field of view (wide) | 70.2° |
| Minimum illumination | 1 lx |
| White balance | Auto, Manual, One push |
| Focus adjustment | Auto/Manual |
| Gain control type | Auto/Manual |
| PTZ control | Yes |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Maximum frame rate | 60 fps |
| HD type | Full HD |
| Resolution at capture speed | 1920x1080@60fps |
| Supported video modes | 1080p |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Mounting type | Stand |
| Tilt angle range | -30 - 90° |
| Pan range | 150 - 150° |
| Tilt speed (max) | 120 °/sec |
| Tilt speed (min) | 0.35 °/sec |
| Pan speed (max) | 120 °/sec |
| Pan speed (min) | 0.35 °/sec |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | PoE |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Cables included | AC |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | Federal Communications Commission (FCC), CE, TAA |
Performance
| Specification | Value |
|---|---|
| Certification | CE,FCC,TAA |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 179.1 mm |
| Depth | 171.4 mm |
| Height | 176.3 mm |
| Weight | 2.2 kg |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 5.9 kg |
