RoboSHOT 12 AVBMP
Model RoboSHOT 12 AVBMPPart no. 999-9900-500EAN 840077502560
42 specifications
- Weight2.2 kg
- ColourBlack, Silver
- Megapixel (approx.)2.34 MP
- Maximum frame rate60 fps
- Power over Ethernet (PoE) ports quantity2
- Operating temperature (T-T)0 - 40 °C
Overview
- Weight
- 2.2 kg
- Colour
- Black, Silver
- Megapixel (approx.)
- 2.34 MP
- Maximum frame rate
- 60 fps
- Power over Ethernet (PoE) ports quantity
- 2
- Operating temperature (T-T)
- 0 - 40 °C
- Brand
- Vaddio
- Category
- Video Conferencing Camera
- Model
- RoboSHOT 12 AVBMP
- Part number
- 999-9900-500
- EAN / UPC
- 840077502560
- Also known as
- Vaddio RoboSHOT 12 AVBMP 2.34 MP Black, Silver 60 fps CMOS 25.4 / 2.8 mm (1 / 2.8")
Specifications
42 specifications in 8 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 2.34 MP |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Optical zoom (normal mode) | 10x |
| Optical zoom (super-wide mode) | 12x |
| Field of view (FOV) angle | 73° |
| Focal length range | 3.91 - 47 mm |
| Focal length range (normal mode) | 3.91 - 47 mm |
| Focal length range (super-wide mode) | 3.8 - 38 mm |
| Recommended illumination range | 1 - 100 lx |
| Minimum illumination | 1 lx |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Aperture range (F-F) | 1.8 - 3.4 |
| Focus adjustment | Auto |
| Closest focusing distance | 0.01 m |
| Lens type | Wide-angle |
| PTZ control | Yes |
| Aspect ratio | 16:9 |
| Maximum working distance (tele) | 800 m |
| Minimum working distance (wide) | 1 cm |
| Sync system | Internal |
Video
| Specification | Value |
|---|---|
| Maximum frame rate | 60 fps |
| HD type | Full HD |
| Supported video modes | 720p, 1080i, 1080p |
Design
| Specification | Value |
|---|---|
| Product colour | Black, Silver |
| Tilt angle range | -30 - 90° |
| Pan range | -160 - 160° |
| Web-based management | Yes |
| Tilt speed (max) | 120 °/sec |
| Tilt speed (min) | 0.35 °/sec |
| Pan speed (max) | 120 °/sec |
| Pan speed (min) | 0.35 °/sec |
Ports & interfaces
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Network
| Specification | Value |
|---|---|
| Ethernet LAN data rates | 10,100 Mbit/s |
Audio
| Specification | Value |
|---|---|
| Noise reduction | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 179.2 mm |
| Depth | 171.6 mm |
| Height | 176.3 mm |
| Weight | 2.2 kg |
