UC W21
Model UC W21Part no. UCW21EAN 6927433601663
34 specifications
- Weight202.5 g
- ColourBlack
- Megapixel (approx.)8.46 MP
- Maximum video resolution3840 x 2160 pixels
- Operating temperature (T-T)0 - 40 °C
- Number of microphones2
Overview
- Weight
- 202.5 g
- Colour
- Black
- Megapixel (approx.)
- 8.46 MP
- Maximum video resolution
- 3840 x 2160 pixels
- Operating temperature (T-T)
- 0 - 40 °C
- Number of microphones
- 2
- Brand
- MAXHUB
- Category
- Video Conferencing Camera
- Model
- UC W21
- Part number
- UCW21
- EAN / UPC
- 6927433601663
- Also known as
- MAXHUB UC W21 8.46 MP Black 3840 x 2160 pixels 30 fps
Specifications
34 specifications in 8 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 8.46 MP |
| Camera type | Single camera |
| Horizontal field of view | 107° |
| Vertical field of view | 70° |
| White balance | Auto |
| Auto exposure | Yes |
| Focus adjustment | Manual |
| Closest focusing distance | 1.5 m |
| Back Light Compensation (BLC) | Yes |
| 3D NR (Noise Reduction) | Yes |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 30 fps |
| HD type | 4K Ultra HD |
| Video formats supported | H.264, MJPG, YUY2 |
| Supported graphics resolutions | 320 x 240, 352 x 288, 480 x 270, 640 x 360, 640 x 480 (VGA), 800 x 600 (SVGA), 960 x 540, 1024 x 576 (WSVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Tilt angle range | -10 - 10° |
| Pan range | -360 - 360° |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Audio
| Specification | Value |
|---|---|
| Number of microphones | 2 |
| Noise reduction | Yes |
| Microphone pick-up range | 4 m |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 117.9 mm |
| Depth | 55.7 mm |
| Height | 51 mm |
| Weight | 202.5 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 147 mm |
| Package depth | 70.5 mm |
| Package height | 91 mm |
| Package weight | 246.3 g |
