UC S15
Model UC S15
38 specifications
- ColourBlack
- Megapixel (approx.)12 MP
- Maximum video resolution3840 x 2160 pixels
- HDMI ports quantity1
- Power source typeDC, PoE
- Wi-FiYes
Overview
- Colour
- Black
- Megapixel (approx.)
- 12 MP
- Maximum video resolution
- 3840 x 2160 pixels
- HDMI ports quantity
- 1
- Power source type
- DC, PoE
- Wi-Fi
- Yes
- Brand
- MAXHUB
- Category
- Video Conferencing Camera
- Model
- UC S15
- Part numbers
- UC S15, MAXHUBUCS15
- Also known as
- MAXHUB UC S15 video conferencing camera 12 MP Black 3840 x 2160 pixels 30 fps Sony 25.4 / 2.3 mm (1 / 2.3")
Specifications
38 specifications in 9 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 12 MP |
| Sensor type | Sony |
| Optical sensor size | 25.4 / 2.3 mm (1 / 2.3") |
| Digital zoom | 5x |
| Field of view (FOV) angle | 120° |
| Voice tracking | Yes |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 30 fps |
| HD type | 4K Ultra HD |
| Supported video modes | 720i, 720p, 1080p |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Mounting type | Stand/Wall mounting |
| Tilt angle range | -15 - 15° |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC, PoE |
| DC input voltage | 12 V |
| Power consumption (max) | 24 W |
Performance
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Auto framing | Yes |
| Cable lock slot type | Kensington |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
| Number of microphones | 6 |
| Microphone sensitivity | 75 dB |
| Sound pressure level (max) | 83 dB |
| Speaker frequency range | 150 - 18000 Hz |
| Echo cancellation | Yes |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Cables included | HDMI, USB |
| USB cable length | 1.8 m |
| Mounting kit | Yes |
| Quick start guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
