UC S07
Model UC S07
41 specifications
- Weight1.05 kg
- ColourBlack
- Megapixel (approx.)12 MP
- Maximum video resolution3840 x 2160 pixels
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
- Power source typeDC
Overview
- Weight
- 1.05 kg
- Colour
- Black
- Megapixel (approx.)
- 12 MP
- Maximum video resolution
- 3840 x 2160 pixels
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 1
- Power source type
- DC
- Brand
- MAXHUB
- Category
- Video Conferencing Camera
- Model
- UC S07
- Part number
- UC S07
- Also known as
- MAXHUB UC S07 video conferencing camera 12 MP Black 3840 x 2160 pixels 25.4 / 2.3 mm (1 / 2.3")
Specifications
41 specifications in 11 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 12 MP |
| Camera type | Single camera |
| Optical sensor size | 25.4 / 2.3 mm (1 / 2.3") |
| Digital zoom | 5x |
| Field of view (FOV) angle | 120° |
| Vertical field of view | 15° |
| Focus adjustment | Manual |
| Closest focusing distance | 1 m |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Video formats supported | H.264, MJPG, YUY2 |
| Supported graphics resolutions | 160 x 120, 320 x 180, 320 x 240, 352 x 288, 480 x 270, 640 x 360, 640 x 480 (VGA), 800 x 600 (SVGA), 960 x 540, 1024 x 576 (WSVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| DC input voltage | 12 V |
| Power consumption (max) | 10 W |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3af, IEEE 802.3at |
Audio
| Specification | Value |
|---|---|
| Number of microphones | 6 |
| Built-in speaker(s) | Yes |
| Sound pressure level (max) | 85 dB |
| Echo cancellation | Yes |
| Noise reduction | Yes |
| Microphone pick-up range | 8 m |
Performance
| Specification | Value |
|---|---|
| Auto framing | Yes |
| Auto-tracking | Yes |
| Tracking modes | Presenter mode |
Packaging content
| Specification | Value |
|---|---|
| Remote control included | Yes |
| Cables included | USB |
| AC adapter included | Yes |
| Mounting kit | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 462 mm |
| Depth | 93 mm |
| Height | 76 mm |
| Weight | 1.05 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 538 mm |
| Package depth | 169 mm |
| Package height | 160 mm |
| Package weight | 2.55 kg |
