UC CAM120UL-1
Model UC CAM120UL-1EAN 4948570033010
28 specifications
- Weight200 g
- ColourBlack
- Megapixel (approx.)8 MP
- Maximum video resolution3840 x 2160 pixels
- USB 2.0 ports quantity1
- Power source typeUSB
Overview
- Weight
- 200 g
- Colour
- Black
- Megapixel (approx.)
- 8 MP
- Maximum video resolution
- 3840 x 2160 pixels
- USB 2.0 ports quantity
- 1
- Power source type
- USB
- Brand
- iiyama
- Category
- Video Conferencing Camera
- Model
- UC CAM120UL-1
- Part number
- UC CAM120UL-1
- EAN / UPC
- 4948570033010, 5704174947004
- Also known as
- iiyama UC CAM120UL-1 video conferencing camera 8 MP Black 3840 x 2160 pixels 30 fps
Specifications
28 specifications in 12 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 8 MP |
| Field of view (FOV) angle | 120° |
| F-number (relative aperture) | 1.8 |
| Closest focusing distance | 1.5 m |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 30 fps |
| HD type | 4K Ultra HD |
| Resolution at capture speed | 1920x1080@30fps, 2560x1440@30fps, 3840x2160@30fps |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Tilt angle range | 0 - 10° |
| Pan range | 0 - 360° |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
| USB Type-C connector | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
| Microphone pick-up range | 4 m |
Performance
| Specification | Value |
|---|---|
| Auto framing | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, REACH, RoHS, WEEE |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85258900 |
Technical details
| Specification | Value |
|---|---|
| Sustainability certificates | ErP |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 118 mm |
| Depth | 48.5 mm |
| Height | 53.4 mm |
| Weight | 200 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 47 mm |
| Package depth | 70.5 mm |
| Package height | 91 mm |
| Package weight | 310 g |
