DH-VCS-C7A0 2.1 MP Black 2048 x 1080 pixels 60 fps CMOS 25.4 / 2.8 mm (1 / 2.8")
Model DH-VCS-C7A0Part no. DH-VCS-C7A0-HDMIEP
38 specifications
- Weight2.5 kg
- ColourBlack
- Megapixel (approx.)2.1 MP
- Maximum video resolution2048 x 1080 pixels
- RS-232 ports1
- Power source typeDC
Overview
- Weight
- 2.5 kg
- Colour
- Black
- Megapixel (approx.)
- 2.1 MP
- Maximum video resolution
- 2048 x 1080 pixels
- RS-232 ports
- 1
- Power source type
- DC
- Brand
- Dahua Technology
- Category
- Video Conferencing Camera
- Model
- DH-VCS-C7A0
- Part number
- DH-VCS-C7A0-HDMIEP
- Also known as
- Dahua Technology DH-VCS-C7A0 2.1 MP Black 2048 x 1080 pixels 60 fps CMOS 25.4 / 2.8 mm (1 / 2.8")
Specifications
38 specifications in 8 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 2.1 MP |
| Camera type | Single camera |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Zoom capability | Yes |
| Optical zoom | 12x |
| Field of view (tele) | 73° |
| Field of view (wide) | 6.55° |
| Focal length range | 3.9 - 46.8 mm |
| Minimum illumination | 1.8 lx |
| Aperture range (F-F) | 1.6 - 2.8 |
| Focus adjustment | Auto/Manual |
| Wide Dynamic Range (WDR) | Yes |
| Number of camera presets | 256 |
| Gain control type | Auto |
| PTZ control | Yes |
| Fastest camera shutter speed | 1/4000 s |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 2048 x 1080 pixels |
| Maximum frame rate | 60 fps |
| HD type | Full HD |
| Supported video modes | 720p, 1080p |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Tilt angle range | -30 - 30° |
| Pan range | 0 - 120° |
Ports & interfaces
| Specification | Value |
|---|---|
| RS-232 ports | 1 |
| RS-485 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| DC input voltage | 12 V |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 245 mm |
| Depth | 166 mm |
| Height | 156 mm |
| Weight | 2.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 674 mm |
| Package depth | 454 mm |
| Package height | 486 mm |
| Package weight | 5 kg |
