VB370A 8 MP Black 3840 x 2160 pixels 30 fps Exmor CMOS
Model VB370APart no. 61U3900000ACEAN 4719552127498
69 specifications
- Weight3.7 kg
- ColourBlack
- Megapixel (approx.)8 MP
- Maximum video resolution3840 x 2160 pixels
- HDMI ports quantity3
- Power source typeDC
Overview
- Weight
- 3.7 kg
- Colour
- Black
- Megapixel (approx.)
- 8 MP
- Maximum video resolution
- 3840 x 2160 pixels
- HDMI ports quantity
- 3
- Power source type
- DC
- Brand
- AVer
- Category
- Video Conferencing Camera
- Model
- VB370A
- Part number
- 61U3900000AC
- EAN / UPC
- 4719552127498
- Also known as
- AVer VB370A 8 MP Black 3840 x 2160 pixels 30 fps Exmor CMOS
Specifications
69 specifications in 13 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 8 MP |
| Camera type | Dual camera |
| Second camera resolution | 8 MP |
| Sensor type | Exmor CMOS |
| Zoom capability | Yes |
| Digital zoom | 4x |
| Combined zoom | 18x |
| Field of view (FOV) angle | 92° |
| Second camera field of view (FOV) angle | 113° |
| Horizontal field of view | 81° |
| Vertical field of view | 50° |
| Flip & mirror | Yes |
| White balance | Auto, Manual |
| Focus adjustment | Auto/Manual |
| Lens type | Wide-angle |
| Second camera lens type | Wide-angle |
| Wide Dynamic Range (WDR) | Yes |
| PTZ control | Yes |
| Face tracking | Yes |
| Photo feature | Yes |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| Maximum frame rate | 30 fps |
| HD type | 4K Ultra HD |
| Supported video modes | 360p, 480p, 540p, 720p, 900p, 1080p, 1440p |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Mounting type | Stand |
| Web-based management | Yes |
| Cable management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 3 |
| USB 2.0 ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| RS-232 ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Line-in | Yes |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100-240 V |
| DC input voltage | 12 V |
| Input current | 7.5 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
System requirements
| Specification | Value |
|---|---|
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Other operating systems supported | iOS |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
| Number of microphones | 1 |
| Number of microphone arrays | 14 |
| Microphone sensitivity | 35 dB |
| Echo cancellation | Yes |
Performance
| Specification | Value |
|---|---|
| Screen mirroring | Yes |
| Auto framing | Yes |
| Auto-tracking | Yes |
| Tracking modes | Presenter mode |
| Tripod mounting supported | Yes |
Packaging content
| Specification | Value |
|---|---|
| Power supply included | Yes |
| Remote control included | Yes |
| Cables included | USB |
| Screws included | Yes |
| Mounting kit | Yes |
| Packaging content | VB350 unit Power adapter & cable USB 3.1 type B to type A cable (3 m) USB 3.1 type A to type C adapter QR code card Wall-mount bracket Tripod Screws Remote control Wall-mount drill paper |
Technical details
| Specification | Value |
|---|---|
| Warranty period | 3 year(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 790 mm |
| Depth | 138 mm |
| Height | 129 mm |
| Weight | 3.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
