HD Video USB Content Camera
Model RXVCam10-CCPart no. RXVCAM10-CC
35 specifications
- Weight150 g
- ColourBlack
- Megapixel (approx.)2 MP
- Maximum video resolution1920 x 1080 pixels
- USB 2.0 ports quantity1
- Power source typeUSB
Overview
- Weight
- 150 g
- Colour
- Black
- Megapixel (approx.)
- 2 MP
- Maximum video resolution
- 1920 x 1080 pixels
- USB 2.0 ports quantity
- 1
- Power source type
- USB
- Brand
- AudioCodes
- Category
- Video Conferencing Camera
- Model
- RXVCam10-CC
- Part number
- RXVCAM10-CC
- Also known as
- AudioCodes HD Video USB Content Camera
Specifications
35 specifications in 10 groups
Camera
| Specification | Value |
|---|---|
| Megapixel (approx.) | 2 MP |
| Camera type | Single camera |
| Sensor type | CMOS |
| Zoom capability | Yes |
| Digital zoom | 3x |
| Focal length range | 3.24 mm |
| Horizontal field of view | 85° |
| Vertical field of view | 52° |
| Minimum illumination | 0.5 lx |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 1920 x 1080 pixels |
| Maximum frame rate | 30 fps |
| HD type | Full HD |
| Video formats supported | H.264, H.265, M-JPEG, YUV2 |
| Supported graphics resolutions | 160 x 120, 320 x 180, 320 x 240, 432 x 240, 480 x 272, 640 x 360, 640 x 480 (VGA), 800 x 448, 800 x 600 (SVGA), 960 x 540, 960 x 720, 1024 x 576 (WSVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | USB |
| DC input voltage | 5 V |
| Power consumption (typical) | 2.5 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | 20 - 95 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
Packaging content
| Specification | Value |
|---|---|
| Cables included | USB |
| USB cable length | 1.8 m |
| Screws included | Yes |
Certificates
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), RCM |
Performance
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 102 mm |
| Depth | 46 mm |
| Height | 30 mm |
| Weight | 150 g |
