Teams RXV81 Video Collaboration Bar (MTRfA)
Model RXV81Part no. TEAMS-RXV81
36 specifications
- OSAndroid 9.0
- ColourBlack
- Camera typeSingle camera
- Maximum video resolution3840 x 2160 pixels
- HDMI ports quantity1
- Power source typeDC
Overview
- OS
- Android 9.0
- Colour
- Black
- Camera type
- Single camera
- Maximum video resolution
- 3840 x 2160 pixels
- HDMI ports quantity
- 1
- Power source type
- DC
- Brand
- AudioCodes
- Category
- Video Conferencing Camera
- Model
- RXV81
- Part numbers
- TEAMS-RXV81, RXV81P
- Also known as
- AudioCodes Teams RXV81 Video Collaboration Bar (MTRfA)
Specifications
36 specifications in 9 groups
Camera
| Specification | Value |
|---|---|
| Camera type | Single camera |
| Zoom capability | Yes |
| Digital zoom | 5x |
| Horizontal field of view | 110° |
| Vertical field of view | 75° |
| PTZ control | Yes |
Video
| Specification | Value |
|---|---|
| Maximum video resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Resolution at capture speed | 1920x1080@30fps |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Tilt angle range | -15 - 15° |
Ports & interfaces
| Specification | Value |
|---|---|
| HDMI ports quantity | 1 |
| Power over Ethernet (PoE) ports quantity | 1 |
| USB 2.0 Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| DC input voltage | 12 V |
| Input current | 3 A |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Supported network protocols | TCP/IP (IPv4) |
Performance
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Operating system installed | Android 9.0 |
Audio
| Specification | Value |
|---|---|
| Built-in microphone | Yes |
| Number of microphone arrays | 6 |
| Built-in speaker(s) | Yes |
| Audio beamforming | Yes |
| Echo cancellation | Yes |
| Noise reduction | Yes |
| Clear Voice technology | Yes |
| Microphone pick-up range | 4.5 m |
Certificates
| Specification | Value |
|---|---|
| Certified for Microsoft Teams | Yes |
