ICA-PLB 3646
Model ICA-PLB 3646EAN 8059018361254
30 specifications
- Weight7.41 kg
- ColourBlack
- Number of displays supported1
- Adjustable depthYes
- Number of joints3
- Width510 mm
Overview
- Weight
- 7.41 kg
- Colour
- Black
- Number of displays supported
- 1
- Adjustable depth
- Yes
- Number of joints
- 3
- Width
- 510 mm
- Brand
- Techly
- Category
- TV Mounts & Stands
- Model
- ICA-PLB 3646
- Part number
- ICA-PLB 3646
- EAN / UPC
- 8059018361254
- Also known as
- Techly ICA-PLB 3646 TV mount/stand 139.7 cm (55") Black
Specifications
30 specifications in 8 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity | 50 kg |
| Minimum screen size | 81.3 cm (32") |
| Maximum screen size | 139.7 cm (55") |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 200 x 200,300 x 300,400 x 200,400 x 400 |
Ergonomics
| Specification | Value |
|---|---|
| Adjustable depth | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -20 - 10° |
| Swivel angle range | -60 - 60° |
| Cable management | Yes |
| Built-in spirit level | No |
| Distance to the wall (max) | 50 cm |
| Distance to the wall (min) | 6.4 cm |
| Suitable for curved screen | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Steel |
| Anti-theft function | No |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Mounting kit | Yes |
Technical details
| Specification | Value |
|---|---|
| Number of joints | 3 |
| Warranty period | 10 year(s) |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 510 mm |
| Depth (max) | 48 cm |
| Height | 430 mm |
| Weight | 7.41 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pair(s) |
Logistics data
| Specification | Value |
|---|---|
| Products per master (outer) case | 1 pc(s) |
