Neomounts WL40S-840BL14 TV mount wall 32-65" - full motion - fast installation

WL40S-840BL14 TV mount wall 32-65" - full motion - fast installation

Model WL40S-840BL14EAN 8717371448844

48 specifications

TypeFull motion
Weight3.85 kg
ColourBlack
Number of displays supported1
Height adjustmentNo
Country of originChina

See all specifications

Overview

Type: Full motion
Weight: 3.85 kg
Colour: Black
Number of displays supported: 1
Height adjustment: No
Country of origin: China

Brand: Neomounts
Category: TV Mounts & Stands
Model: WL40S-840BL14
Part number: WL40S-840BL14
EAN / UPC: 8717371448844
Also known as: Neomounts WL40S-840BL14 TV mount wall 32-65" - full motion - fast installation

Specifications

48 specifications in 8 groups

Mounting

Specification	Value
Number of displays supported	1
Maximum weight capacity (per display)	40 kg
Maximum weight capacity	40 kg
Minimum screen size	81.3 cm (32")
Maximum screen size	165.1 cm (65")
Mounting type	Wall
Minimum VESA mount	100 x 100 mm
Maximum VESA mount	400 x 400 mm
Panel mounting interface	100 x 200,100 x 100,100 x 150,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400

Ergonomics

Specification	Value
Height adjustment	No
Tilt adjustment	Yes
Tilt angle range	-2 - 12°
Swivelling	Yes
Swivel angle	25°
Swivel angle range	0 - 25°
Rotating	Yes
Angle of rotation	6°
Pivot angle	-3 - 3°
Cable management	Yes
Type	Full motion
Distance to the wall (max)	34.5 cm
Distance to the wall (min)	4.9 cm

Design

Specification	Value
Product colour	Black
Housing material	Steel

Packaging content

Specification	Value
Hex key included	Yes
Mounting kit	Yes
Number of wrenches included	1

Technical details

Specification	Value
Country of origin	China
Quantity per pack	1 pc(s)
Lockable	Not lockable
Package net weight	5 kg

Weight & dimensions

Specification	Value
Width	449 mm
Depth	49 mm
Depth (max)	4.9 cm
Height	449 mm
Weight	3.85 kg

Packaging data

Specification	Value
Package width	511 mm
Package depth	332 mm
Package height	62 mm
Package weight	5 kg

Logistics data

Specification	Value
Master (outer) case width	530 mm
Master (outer) case length	267 mm
Master (outer) case height	355 mm
Master (outer) case gross weight	20.4 kg
Master (outer) case net weight	16.4 kg
Products per master (outer) case	4 pc(s)
Harmonized System (HS) code	7326909890
Products per pallet (EU)	96 pc(s)
