ICA-PLB 192
Model ICA-PLB 192EAN 8059018369380
27 specifications
- Weight16.1 kg
- ColourBlack
- Number of displays supported1
- Adjustable depthYes
- Extension arm (max)72 cm
- Width985 mm
Overview
- Weight
- 16.1 kg
- Colour
- Black
- Number of displays supported
- 1
- Adjustable depth
- Yes
- Extension arm (max)
- 72 cm
- Width
- 985 mm
- Brand
- Techly
- Category
- TV Mounts & Stands
- Model
- ICA-PLB 192
- Part number
- ICA-PLB 192
- EAN / UPC
- 8059018369380
- Also known as
- Techly Wall Bracket Full-Motion for 65-110" LED LCD TV
Specifications
27 specifications in 7 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity (per display) | 120 kg |
| Maximum weight capacity | 120 kg |
| Minimum screen size | 165.1 cm (65") |
| Maximum screen size | 2.79 m (110") |
| Mounting type | Wall |
| Minimum VESA mount | 300 x 300 mm |
| Maximum VESA mount | 900 x 600 mm |
| Panel mounting interface | 300 x 300,400 x 400,600 x 400,600 x 600,800 x 400,800 x 500,800 x 600,900 x 600 |
Ergonomics
| Specification | Value |
|---|---|
| Adjustable depth | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | 0 - 7° |
| Rotating | Yes |
| Angle of rotation | 120° |
| Built-in spirit level | Yes |
| Distance to the wall (min) | 4 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Steel |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
Technical details
| Specification | Value |
|---|---|
| Extension arm (max) | 72 cm |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 985 mm |
| Depth (min) | 4 cm |
| Depth (max) | 72 cm |
| Height | 630 mm |
| Weight | 16.1 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pair(s) |
| Package type | Box |
