PA746 TV mount/stand
127 cm (50") Black
Model PA746EAN 190283093032
27 specifications
- Weight2.45 kg
- ColourBlack
- Maximum weight capacity36 kg
- Tilt adjustmentYes
- Width423 mm
Overview
- Weight
- 2.45 kg
- Colour
- Black
- Maximum weight capacity
- 36 kg
- Tilt adjustment
- Yes
- Width
- 423 mm
- Brand
- Peerless
- Category
- TV Mounts & Stands
- Model
- PA746
- Part number
- PA746
- EAN / UPC
- 190283093032, 735029304258, 5054629948088
- Also known as
- Peerless PA746 TV mount/stand 127 cm (50") Black
Specifications
27 specifications in 7 groups
Mounting
| Specification | Value |
|---|---|
| Maximum weight capacity | 36 kg |
| Minimum screen size | 81.3 cm (32") |
| Maximum screen size | 127 cm (50") |
| Mounting type | Wall |
| Minimum VESA mount | 100 x 100 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 100 x 100,200 x 100,300 x 200,400 x 400,400 x 300 |
Ergonomics
| Specification | Value |
|---|---|
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 15° |
| Pivot angle | -90 - 90° |
| Cable management | Yes |
| Distance to the wall (max) | 37.5 cm |
| Distance to the wall (min) | 5.9 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Certification | RoHS, UL |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Mounting kit | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 423 mm |
| Depth (min) | 7.1 cm |
| Depth (max) | 38.3 cm |
| Height | 432 mm |
| Weight | 2.45 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 270 mm |
| Package depth | 299 mm |
| Package height | 82 mm |
| Package weight | 3.11 kg |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85299097 |
