Neomounts WL35S-850BL14 TV mount wall 40-75" - tiltable - lockable - fast installation

WL35S-850BL14 TV mount wall 40-75" - tiltable - lockable - fast installation

Model WL35S-850BL14EAN 8717371448820

37 specifications

Weight2.65 kg
ColourBlack
Number of displays supported1
Height adjustmentYes
Country of originChina
Width484 mm

See all specifications

Overview

Weight: 2.65 kg
Colour: Black
Number of displays supported: 1
Height adjustment: Yes
Country of origin: China
Width: 484 mm

Brand: Neomounts
Category: TV Mounts & Stands
Model: WL35S-850BL14
Part number: WL35S-850BL14
EAN / UPC: 8717371448820
Also known as: Neomounts WL35S-850BL14 TV mount wall 40-75" - tiltable - lockable - fast installation

Specifications

37 specifications in 7 groups

Mounting

Specification	Value
Number of displays supported	1
Maximum weight capacity (per display)	50 kg
Maximum weight capacity	50 kg
Minimum screen size	101.6 cm (40")
Maximum screen size	190.5 cm (75")
Mounting type	Wall
Minimum VESA mount	100 x 100 mm
Maximum VESA mount	400 x 400 mm
Panel mounting interface	100 x 200,100 x 100,100 x 150,120 x 120,150 x 200,200 x 100,200 x 150,200 x 200,200 x 300,200 x 400,300 x 100,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400

Ergonomics

Specification	Value
Height adjustment	Yes
Height adjustment range	0 - 20 mm
Tilt adjustment	Yes
Tilt angle range	0 - 12°
Distance to the wall (max)	3.5 cm

Design

Specification	Value
Product colour	Black
Housing material	Steel

Technical details

Specification	Value
Country of origin	China
Quantity per pack	1 pc(s)
Lockable	Security screw included
Package net weight	3.7 kg

Weight & dimensions

Specification	Value
Width	484 mm
Depth	35 mm
Depth (max)	3.5 cm
Height	425 mm
Weight	2.65 kg

Packaging data

Specification	Value
Package width	704 mm
Package depth	158 mm
Package height	74 mm
Package weight	3.7 kg

Logistics data

Specification	Value
Master (outer) case width	724 mm
Master (outer) case length	240 mm
Master (outer) case height	343 mm
Master (outer) case gross weight	22.9 kg
Master (outer) case net weight	18.5 kg
Products per master (outer) case	6 pc(s)
Harmonized System (HS) code	7326909890
Products per pallet (EU)	120 pc(s)
