Neomounts PLASMA-C100D Dual monitor/TV mount ceiling 37-75" - h 67-107 cm

PLASMA-C100D Dual monitor/TV mount ceiling 37-75" - h 67-107 cm

Model PLASMA-C100DEAN 8717371441739

35 specifications

Weight20.9 kg
ColourBlack
Number of displays supported2
Height adjustmentYes
Country of originTaiwan
Height1070 mm

See all specifications

Overview

Weight: 20.9 kg
Colour: Black
Number of displays supported: 2
Height adjustment: Yes
Country of origin: Taiwan
Height: 1070 mm

Brand: Neomounts
Category: TV Mounts & Stands
Model: PLASMA-C100D
Part number: PLASMA-C100D
EAN / UPC: 8717371441739
Also known as: Neomounts PLASMA-C100D Dual monitor/TV mount ceiling 37-75" - h 67-107 cm

Specifications

35 specifications in 7 groups

Mounting

Specification	Value
Number of displays supported	2
Maximum weight capacity (per display)	50 kg
Maximum weight capacity	50 kg
Minimum screen size	94 cm (37")
Maximum screen size	190.5 cm (75")
Mounting type	Ceiling
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	800 x 450 mm
Panel mounting interface	200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,440 x 400,500 x 400,600 x 300,600 x 200,600 x 400,680 x 300,800 x 200,800 x 400

Ergonomics

Specification	Value
Height adjustment	Yes
Height adjustment type	Manual
Height adjustment range	670 - 1070 mm
Tilt adjustment	Yes
Tilt angle range	0 - 25°
Swivelling	Yes
Swivel angle	60°
Swivel angle range	0 - 60°
Tilt angle	25°

Design

Specification	Value
Product colour	Black
Housing material	Steel

Technical details

Specification	Value
Country of origin	Taiwan

Weight & dimensions

Specification	Value
Height	1070 mm
Weight	20.9 kg

Packaging data

Specification	Value
Package width	950 mm
Package depth	280 mm
Package height	260 mm
Package weight	22 kg

Logistics data

Specification	Value
Master (outer) case width	950 mm
Master (outer) case length	280 mm
Master (outer) case height	260 mm
Master (outer) case gross weight	24.3 kg
Master (outer) case net weight	22 kg
Products per master (outer) case	1 pc(s)
Harmonized System (HS) code	7326909890
Products per pallet (EU)	18 pc(s)
