Neomounts PLASMA-C100 Monitor/TV mount ceiling 37-75" - h 67-107 cm

PLASMA-C100 Monitor/TV mount ceiling 37-75" - h 67-107 cm

Model PLASMA-C100EAN 5711045058806

38 specifications

Weight16.6 kg
ColourSilver
Number of displays supported1
Height adjustmentYes
Country of originTaiwan
Depth80 mm

See all specifications

Overview

Weight: 16.6 kg
Colour: Silver
Number of displays supported: 1
Height adjustment: Yes
Country of origin: Taiwan
Depth: 80 mm

Brand: Neomounts
Category: TV Mounts & Stands
Model: PLASMA-C100
Part number: PLASMA-C100
EAN / UPC: 5711045058806, 8717371441067
Also known as: Neomounts PLASMA-C100 Monitor/TV mount ceiling 37-75" - h 67-107 cm

Specifications

38 specifications in 8 groups

Mounting

Specification	Value
Number of displays supported	1
Maximum weight capacity (per display)	50 kg
Maximum weight capacity	50 kg
Minimum screen size	94 cm (37")
Maximum screen size	190.5 cm (75")
Mounting type	Ceiling
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	800 x 450 mm
Panel mounting interface	200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,440 x 400,500 x 400,600 x 300,600 x 200,600 x 400,680 x 300,800 x 200,800 x 400

Ergonomics

Specification	Value
Height adjustment	Yes
Height adjustment type	Manual
Height adjustment range	670 - 1070 mm
Tilt adjustment	Yes
Tilt angle range	0 - 25°
Swivelling	Yes
Swivel angle	60°
Swivel angle range	0 - 60°
Tilt angle	25°
Distance to the wall (min)	7.8 cm

Design

Specification	Value
Product colour	Silver
Housing material	Steel

Technical details

Specification	Value
Country of origin	Taiwan

Weight & dimensions

Specification	Value
Depth	80 mm
Height	1070 mm
Weight	16.6 kg

Packaging data

Specification	Value
Package width	880 mm
Package depth	260 mm
Package height	280 mm
Package weight	17.5 kg

Logistics data

Specification	Value
Master (outer) case width	880 mm
Master (outer) case length	260 mm
Master (outer) case height	280 mm
Master (outer) case gross weight	18.3 kg
Master (outer) case net weight	17.5 kg
Products per master (outer) case	1 pc(s)
Harmonized System (HS) code	7326909890
Products per pallet (EU)	21 pc(s)

Other features

Specification	Value
Depth adjustment range	0 - 80 mm
