tv wall mount
Model LED-W800Part no. LED-W800BLACKEAN 8717371445799
26 specifications
- ColourBlack
- Number of displays supported1
- Tilt angle range0 - 20°
- Country of originChina
Overview
- Colour
- Black
- Number of displays supported
- 1
- Tilt angle range
- 0 - 20°
- Country of origin
- China
- Brand
- Neomounts
- Category
- TV Mounts & Stands
- Model
- LED-W800
- Part number
- LED-W800BLACK
- EAN / UPC
- 8717371445799
- Also known as
- Neomounts tv wall mount
Specifications
26 specifications in 6 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity | 40 kg |
| Minimum screen size | 94 cm (37") |
| Maximum screen size | 177.8 cm (70") |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 600 x 400 mm |
Ergonomics
| Specification | Value |
|---|---|
| Tilt angle range | 0 - 20° |
| Swivel angle | 180° |
| Angle of rotation | 6° |
| Distance to the wall (max) | 68 cm |
| Distance to the wall (min) | 4 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Technical details
| Specification | Value |
|---|---|
| Country of origin | China |
| Package net weight | 5.33 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 298 mm |
| Package depth | 82 mm |
| Package height | 875 mm |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 890 mm |
| Master (outer) case length | 180 mm |
| Master (outer) case height | 315 mm |
| Master (outer) case gross weight | 13.4 kg |
| Master (outer) case net weight | 10.7 kg |
| Products per master (outer) case | 2 pc(s) |
| Harmonized System (HS) code | 85299097 |
| Products per pallet (EU) | 40 pc(s) |
