tv wall mount
Model LED-W420BLACKEAN 8717371446321
36 specifications
- TypeFull motion
- ColourBlack
- Number of displays supported1
- Tilt adjustmentYes
- Country of originChina
Overview
- Type
- Full motion
- Colour
- Black
- Number of displays supported
- 1
- Tilt adjustment
- Yes
- Country of origin
- China
- Brand
- Neomounts
- Category
- TV Mounts & Stands
- Model
- LED-W420BLACK
- Part number
- LED-W420BLACK
- EAN / UPC
- 8717371446321
- Also known as
- Neomounts tv wall mount
Specifications
36 specifications in 6 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity (per display) | 35 kg |
| Maximum weight capacity | 35 kg |
| Minimum screen size | 58.4 cm (23") |
| Maximum screen size | 139.7 cm (55") |
| Mounting type | Wall |
| Suitable for computer monitor | Yes |
| Minimum VESA mount | 100 x 100 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 100 x 200,100 x 100,200 x 100,200 x 200,200 x 300,200 x 400,300 x 100,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400 |
Ergonomics
| Specification | Value |
|---|---|
| Tilt adjustment | Yes |
| Tilt angle range | 0 - 13° |
| Swivelling | Yes |
| Swivel angle | 180° |
| Swivel angle range | 0 - 180° |
| Rotating | Yes |
| Angle of rotation | 10° |
| Type | Full motion |
| Distance to the wall (max) | 28 cm |
| Distance to the wall (min) | 6 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Steel |
Technical details
| Specification | Value |
|---|---|
| Country of origin | China |
| Package net weight | 2.6 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 234 mm |
| Package depth | 56 mm |
| Package height | 400 mm |
| Package weight | 0 g |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 490 mm |
| Master (outer) case length | 420 mm |
| Master (outer) case height | 310 mm |
| Master (outer) case gross weight | 25.7 kg |
| Master (outer) case net weight | 21.9 kg |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 7326909890 |
| Products per pallet (EU) | 150 pc(s) |
