Neomounts FPMA-W820 Monitor/TV mount wall 10-27" - full motion

FPMA-W820 Monitor/TV mount wall 10-27" - full motion

Model FPMA-W820EAN 8717371441241

37 specifications

TypeFull motion
Weight830 g
ColourSilver
Number of displays supported1
Tilt adjustmentYes
Country of originChina

See all specifications

Overview

Type: Full motion
Weight: 830 g
Colour: Silver
Number of displays supported: 1
Tilt adjustment: Yes
Country of origin: China

Brand: Neomounts
Category: TV Mounts & Stands
Model: FPMA-W820
Part number: FPMA-W820
EAN / UPC: 8717371441241, 4056324539029, 5052180745702, 5054484736448 +2 more
Also known as: Neomounts FPMA-W820 Monitor/TV mount wall 10-27" - full motion

Specifications

37 specifications in 8 groups

Mounting

Specification	Value
Number of displays supported	1
Maximum weight capacity (per display)	15 kg
Maximum weight capacity	15 kg
Minimum screen size	25.4 cm (10")
Maximum screen size	68.6 cm (27")
Mounting type	Wall
Minimum VESA mount	75 x 75 mm
Maximum VESA mount	100 x 100 mm
Panel mounting interface	100 x 100,75 x 75 mm

Ergonomics

Specification	Value
Tilt adjustment	Yes
Tilt angle range	0 - 90°
Swivelling	Yes
Swivel angle	180°
Swivel angle range	0 - 180°
Rotating	Yes
Type	Full motion
Distance to the wall (max)	25 cm
Distance to the wall (min)	5 cm

Design

Specification	Value
Product colour	Silver
Housing material	Aluminium
Compatibility	LCD/LED/TFT

Technical details

Specification	Value
Country of origin	China
Package net weight	1 kg

Weight & dimensions

Specification	Value
Weight	830 g

Packaging data

Specification	Value
Package width	178 mm
Package depth	50 mm
Package height	285 mm
Package weight	1 kg

Logistics data

Specification	Value
Master (outer) case width	375 mm
Master (outer) case length	340 mm
Master (outer) case height	310 mm
Master (outer) case gross weight	13 kg
Master (outer) case net weight	12 kg
Products per master (outer) case	12 pc(s)
Harmonized System (HS) code	7616991099
Products per pallet (EU)	360 pc(s)

Other features

Specification	Value
Mounting interface	VESA
