M Universal Digital Signage Wallmount Black
Model 7136EAN 7350022737136
31 specifications
- Weight5.25 kg
- ColourBlack
- Number of displays supported1
- RotatingYes
- Width642 mm
Overview
- Weight
- 5.25 kg
- Colour
- Black
- Number of displays supported
- 1
- Rotating
- Yes
- Width
- 642 mm
- Brand
- Multibrackets
- Category
- TV Mounts & Stands
- Model
- 7136
- Part number
- 7136
- EAN / UPC
- 7350022737136
- Also known as
- Multibrackets M Universal Digital Signage Wallmount Black
Specifications
31 specifications in 7 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity | 50 kg |
| Minimum screen size | 81.3 cm (32") |
| Maximum screen size | 160 cm (63") |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 600 x 400 mm |
| Panel mounting interface | 200 x 200,300 x 200,300 x 300,400 x 200,400 x 400,600 x 400 |
Ergonomics
| Specification | Value |
|---|---|
| Rotating | Yes |
| Angle of rotation | 360° |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Technical details
| Specification | Value |
|---|---|
| Metal packaging weight | 5.25 kg |
| Paper/cardboard packaging weight | 520 g |
| Plastic packaging weight | 120 g |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 642 mm |
| Depth (max) | 5.1 cm |
| Height | 440 mm |
| Weight | 5.25 kg |
| Aluminium content weight | 5.25 kg |
| Steel content weight | 0 g |
| Other metals content weight | 0 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 270 mm |
| Package depth | 635 mm |
| Package height | 50 mm |
| Package weight | 5.89 kg |
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Shipping (inner) case width | 66.5 cm |
| Shipping (inner) case length | 24.5 cm |
| Shipping (inner) case height | 29.5 cm |
| Shipping (inner) case gross weight | 24 kg |
| Products per shipping (inner) case | 4 pc(s) |
