M Universal Wallmount Outdoor Tilt 600 MAX
Model 6690EAN 7350073736690
26 specifications
- Weight3.4 kg
- ColourBlack
- Number of displays supported1
- Tilt adjustmentYes
- Metal packaging weight2.94 kg
- Width704 mm
Overview
- Weight
- 3.4 kg
- Colour
- Black
- Number of displays supported
- 1
- Tilt adjustment
- Yes
- Metal packaging weight
- 2.94 kg
- Width
- 704 mm
- Brand
- Multibrackets
- Category
- TV Mounts & Stands
- Model
- 6690
- Part number
- 6690
- EAN / UPC
- 7350073736690
- Also known as
- Multibrackets M Universal Wallmount Outdoor Tilt 600 MAX
Specifications
26 specifications in 7 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity | 50 kg |
| Minimum screen size | 101.6 cm (40") |
| Maximum screen size | 190.5 cm (75") |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 600 x 400 mm |
| Panel mounting interface | 200 x 200,300 x 300,300 x 200,400 x 200,400 x 400,400 x 300,600 x 400 |
Ergonomics
| Specification | Value |
|---|---|
| Tilt adjustment | Yes |
| Tilt angle range | 0 - 12° |
| Distance to the wall (max) | 3.3 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Technical details
| Specification | Value |
|---|---|
| Metal packaging weight | 2.94 kg |
| Paper/cardboard packaging weight | 1 kg |
| Plastic packaging weight | 60 g |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 704 mm |
| Depth (max) | 7.4 cm |
| Height | 158 mm |
| Weight | 3.4 kg |
Packaging data
| Specification | Value |
|---|---|
| Package width | 160 mm |
| Package depth | 710 mm |
| Package height | 800 mm |
| Package weight | 4 kg |
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Shipping (inner) case gross weight | 24 kg |
| Products per shipping (inner) case | 6 pc(s) |
