Equip 55"-86" Interactive Up-Down TV Wall Mount

55"-86" Interactive Up-Down TV Wall Mount

Model 650345EAN 4015867237656

32 specifications

Weight25.8 kg
ColourBlack
Number of displays supported1
Height adjustmentYes
Compliance certificatesRoHS
Width700 mm

See all specifications

Overview

Weight: 25.8 kg
Colour: Black
Number of displays supported: 1
Height adjustment: Yes
Compliance certificates: RoHS
Width: 700 mm

Brand: Equip
Category: TV Mounts & Stands
Model: 650345
Part number: 650345
EAN / UPC: 4015867237656
Also known as: Equip 55"-86" Interactive Up-Down TV Wall Mount

Specifications

32 specifications in 8 groups

Mounting

Specification	Value
Number of displays supported	1
Maximum weight capacity	65 kg
Minimum screen size	139.7 cm (55")
Maximum screen size	2.18 m (86")
Mounting type	Wall
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	600 x 600 mm
Panel mounting interface	200 x 200,200 x 300,200 x 400,300 x 200,300 x 400,300 x 300,350 x 350,400 x 200,400 x 400,400 x 300,400 x 600,600 x 200,600 x 400,600 x 600,600 x 300

Ergonomics

Specification	Value
Height adjustment	Yes
Height adjustment type	Manual
Cable management	Yes
Distance to the wall (max)	9.6 cm

Design

Specification	Value
Product colour	Black
Housing material	Aluminium, Plastic, Steel
Anti-theft function	Yes

Packaging content

Specification	Value
Screws included	Yes

Technical details

Specification	Value
Compliance certificates	RoHS
Country of origin	China

Weight & dimensions

Specification	Value
Width	700 mm
Depth (max)	9.6 cm
Height	696 mm
Weight	25.8 kg

Packaging data

Specification	Value
Package width	835 mm
Package depth	810 mm
Package height	135 mm
Package weight	29.5 kg

Logistics data

Specification	Value
Master (outer) case width	835 mm
Master (outer) case length	810 mm
Master (outer) case height	135 mm
Master (outer) case gross weight	29.5 kg
Products per master (outer) case	1 pc(s)
Customs product code (TARIC)	8529909700
