37"-80" Universal Rotating Wall Bracket
Model 650331EAN 4015867227138
31 specifications
- Weight4.7 kg
- ColourBlack
- Number of displays supported1
- Pan range-180 - 180°
- Compliance certificatesRoHS
- Width630 mm
Overview
- Weight
- 4.7 kg
- Colour
- Black
- Number of displays supported
- 1
- Pan range
- -180 - 180°
- Compliance certificates
- RoHS
- Width
- 630 mm
- Brand
- Equip
- Category
- TV Mounts & Stands
- Model
- 650331
- Part number
- 650331
- EAN / UPC
- 4015867227138
- Also known as
- Equip 37"-80" Universal Rotating Wall Bracket
Specifications
31 specifications in 8 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity | 50 kg |
| Minimum screen size | 94 cm (37") |
| Maximum screen size | 2.03 m (80") |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 600 x 400 mm |
| Panel mounting interface | 200 x 200,300 x 200,300 x 300,350 x 350,400 x 200,400 x 400,400 x 300,400 x 600,600 x 400 |
Ergonomics
| Specification | Value |
|---|---|
| Pan range | -180 - 180° |
| Cable management | No |
| Distance to the wall (max) | 4.5 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Aluminium, Plastic, Stainless steel |
| Anti-theft function | No |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
| Mounting kit | Yes |
| Screw nuts included | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Country of origin | China |
| Orientation | Landscape/Portrait |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 630 mm |
| Depth (max) | 45 cm |
| Height | 45 mm |
| Weight | 4.7 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pair(s) |
| Package width | 255 mm |
| Package depth | 44 mm |
| Package height | 660 mm |
| Package weight | 5.12 kg |
| Package type | Box |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85299097 |
