650327 43"-80" Long Arm Full Motion TV Wall Mount Bracket
Model 650327EAN 4015867225400
24 specifications
- Weight11.5 kg
- ColourBlack
- Number of displays supported1
- Tilt adjustmentYes
- Country of originChina
- Width1015 mm
Overview
- Weight
- 11.5 kg
- Colour
- Black
- Number of displays supported
- 1
- Tilt adjustment
- Yes
- Country of origin
- China
- Width
- 1015 mm
- Brand
- Equip
- Category
- TV Mounts & Stands
- Model
- 650327
- Part number
- 650327
- EAN / UPC
- 4015867225400
- Also known as
- Equip 650327 43"-80" Long Arm Full Motion TV Wall Mount Bracket
Specifications
24 specifications in 8 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity | 50 kg |
| Minimum screen size | 109.2 cm (43") |
| Maximum screen size | 2.03 m (80") |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 800 x 400 mm |
| Panel mounting interface | 200 x 200,300 x 200,300 x 300,400 x 200,400 x 400,400 x 300,600 x 400,800 x 400 |
Ergonomics
| Specification | Value |
|---|---|
| Tilt adjustment | Yes |
| Tilt angle range | -15 - 5° |
| Pan range | -90 - 90° |
| Distance to the wall (max) | 101.5 cm |
| Distance to the wall (min) | 8.2 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Stainless steel |
| Certification | ROHS |
Packaging content
| Specification | Value |
|---|---|
| Mounting kit | Yes |
Technical details
| Specification | Value |
|---|---|
| Country of origin | China |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 1015 mm |
| Depth (max) | 43 cm |
| Height | 885 mm |
| Weight | 11.5 kg |
Packaging data
| Specification | Value |
|---|---|
| Quantity per pack | 1 pair(s) |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85299097 |
