32"-55" Flat Screen Tilt Wall Mount Bracket
Model 650312
17 specifications
- Weight3.19 kg
- ColourBlack
- Number of displays supported1
- Tilt angle range-10 - 5°
- Width440 mm
Overview
- Weight
- 3.19 kg
- Colour
- Black
- Number of displays supported
- 1
- Tilt angle range
- -10 - 5°
- Width
- 440 mm
- Brand
- Equip
- Category
- TV Mounts & Stands
- Model
- 650312
- Part number
- 650312
- Also known as
- Equip 32"-55" Flat Screen Tilt Wall Mount Bracket
Specifications
17 specifications in 5 groups
Mounting
| Specification | Value |
|---|---|
| Number of displays supported | 1 |
| Maximum weight capacity | 40 kg |
| Minimum screen size | 81.3 cm (32") |
| Maximum screen size | 139.7 cm (55") |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 200 x 200,300 x 300,400 x 200,400 x 400 |
Ergonomics
| Specification | Value |
|---|---|
| Tilt angle range | -10 - 5° |
| Distance to the wall (min) | 5.1 cm |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Steel |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 615 mm |
| Height | 40 mm |
| Weight | 3.19 kg |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
