32309 touch control panel
25.4 cm (10") 1280 x 800 pixels
Model 32309EAN 4002888323093
28 specifications
- Display25.4 cm (10")
- Resolution1280 x 800 pixels
- Memory32000 MB
- OSAndroid
- Weight887 g
- ColourGrey
Overview
- Display
- 25.4 cm (10")
- Resolution
- 1280 x 800 pixels
- Memory
- 32000 MB
- OS
- Android
- Weight
- 887 g
- Colour
- Grey
- Brand
- Lindy
- Category
- Touch Control Panel
- Model
- 32309
- Part number
- 32309
- EAN / UPC
- 4002888323093
- Also known as
- Lindy 32309 touch control panel 25.4 cm (10") 1280 x 800 pixels
Specifications
28 specifications in 9 groups
Display
| Specification | Value |
|---|---|
| Display diagonal | 25.4 cm (10") |
| Display resolution | 1280 x 800 pixels |
| Touchscreen technology | Capacitive |
| Native aspect ratio | 16:10 |
Performance
| Specification | Value |
|---|---|
| Internal memory | 32000 MB |
| RAM capacity | 4000 MB |
| Product colour | Grey |
| Housing material | Aluminium |
| Mean time between failures (MTBF) | 30000 h |
| Operating system installed | Android |
| Operating system version | 11 |
Ports & interfaces
| Specification | Value |
|---|---|
| RJ-45 ports quantity | 1 |
Power
| Specification | Value |
|---|---|
| Power source type | DC |
| Input voltage | 24 V |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 245.4 mm |
| Depth | 164 mm |
| Height | 27 mm |
| Weight | 887 g |
Packaging data
| Specification | Value |
|---|---|
| Package depth | 209 mm |
| Package height | 65 mm |
| Package weight | 1 kg |
| Package width | 375 mm |
| Package type | Box |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Other features
| Specification | Value |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), UKCA, REACH, RoHS |
