SERVER 3230 G6 6369P/64/2x1.9/C/RPSU
Model SERVER 3230 G6 6369P/64/2x1.9/C/RPSUPart no. 1100419EAN 4039407090112
60 specifications
- ProcessorIntel® Xeon®
- Memory64 GB
- Storage3.84 TB
- OSNo
- Processor manufacturerIntel
- On-board graphics cardYes
Overview
- Processor
- Intel® Xeon®
- Memory
- 64 GB
- Storage
- 3.84 TB
- OS
- No
- Processor manufacturer
- Intel
- On-board graphics card
- Yes
- Brand
- TERRA
- Category
- Server
- Model
- SERVER 3230 G6 6369P/64/2x1.9/C/RPSU
- Part number
- 1100419
- EAN / UPC
- 4039407090112
- Also known as
- TERRA 3230 G6 6369P/64/2x1.9/C/RPSU server 3.84 TB Rack Intel® Xeon® 3.3 GHz 64 GB DDR5-SDRAM 800 W
Specifications
60 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® |
| Processor model | 6369P |
| Processor frequency | 3.3 GHz |
| Processor boost frequency | 5.7 GHz |
| Performance cores | 8 |
| Processor cores | 8 |
| Processor cache | 24 MB |
| Motherboard chipset | Intel C266 |
| Memory channels supported by processor | Dual |
| Number of processors installed | 1 |
| Maximum number of SMP processors | 1 |
| Processor socket | LGA 1700 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Internal memory type | DDR5-SDRAM |
| ECC | Yes |
| Maximum internal memory | 128 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 3.84 TB |
| Number of SSDs installed | 2 |
| SSD capacity | 3.84 TB |
| SSD interface | SATA III |
| RAID support | Yes |
| RAID levels | 1 |
| Supported RAID controllers | Broadcom MegaRAID 9560-8i |
| Number of 5.25" bays | 1 |
| Internal drive bays | 8x 3.5"/2.5" |
| Optical drive type | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card family | Aspeed |
| On-board graphics card model | Aspeed AST2600 |
| Maximum graphics card memory | 64 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| LAN controller | Intel X710-AT2 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x8 (Gen 4.x) slots | 2 |
| PCI Express x8 (Gen 5.x) slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack |
| Cooling type | Active |
| Rack mounting | Yes |
Performance
| Specification | Value |
|---|---|
| Remote administration | Ja |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Windows Server 2019¦ |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Power supply | 800 W |
| Number of main power supplies | 2 |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 75% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 438 mm |
| Depth | 660 mm |
| Height | 87 mm |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | CE |
Other features
| Specification | Value |
|---|---|
| Memory type | 4x DDR5 PC4400, UB ECC |
| Motherboard manufacturer | Asus P13R-E/10G-2T |
