MINISERVER G4 E-2224/16
Model MINISERVER G4 E-2224/16Part no. 1100188EAN 4039407055098
41 specifications
- ProcessorIntel Xeon E
- Memory16 GB
- Storage960 GB
- GraphicsAspeed AST2500
- OSNo
- Weight16.5 kg
Overview
- Processor
- Intel Xeon E
- Memory
- 16 GB
- Storage
- 960 GB
- Graphics
- Aspeed AST2500
- OS
- No
- Weight
- 16.5 kg
- Brand
- TERRA
- Category
- Server
- Model
- MINISERVER G4 E-2224/16
- Part number
- 1100188
- EAN / UPC
- 4039407055098
- Also known as
- TERRA MINISERVER G4 E-2224/16 server 960 GB Mini Tower Intel Xeon E 3.4 GHz 16 GB DDR4-SDRAM 400 W
Specifications
41 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel Xeon E |
| Processor frequency | 3.4 GHz |
| Processor boost frequency | 4.6 GHz |
| Processor cores | 4 |
| Processor cache | 8 MB |
| Motherboard chipset | Intel C242 |
| Number of processors installed | 1 |
| Processor cache type | L2 |
| Processor socket | LGA 1151 (Socket H4) |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Buffered memory type | Unregistered (unbuffered) |
| ECC | Yes |
| Memory slots | 2x DIMM |
| Maximum internal memory | 64 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 960 GB |
| Number of SSDs installed | 2 |
| SSD capacity | 480 GB |
| SSD interface | SATA |
| RAID support | Yes |
| RAID levels | 1 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card model | Aspeed AST2500 |
| Maximum graphics card memory | 32 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet, 100 Gigabit Ethernet, Gigabit Ethernet |
| LAN controller | Intel® I210-AT |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini Tower |
| Product colour | Black |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Windows Server 2019 Windows Server 2016 |
Power
| Specification | Value |
|---|---|
| Power supply | 400 W |
| Power supply input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 200 mm |
| Depth | 340 mm |
| Height | 270 mm |
| Weight | 16.5 kg |
