TERRA MINISERVER G3

Model TERRA MINISERVER G3Part no. 1100979EAN 4039407043415

90 specifications

Overview

Brand: TERRA
Category: Server
Model: TERRA MINISERVER G3
Part numbers: 1100979, 1100989
EAN / UPC: 4039407043415, 4039407044368
Also known as: TERRA MINISERVER G3 server 480 GB Mini Tower Intel® Xeon® E3 v6 E3-1220 v6 3 GHz 16 GB DDR4-SDRAM 400 W

90 specifications in 14 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 v6
Processor model	E3-1220 v6
Processor frequency	3 GHz
Processor boost frequency	3.5 GHz
Processor cores	4
Processor cache	8 MB
Motherboard chipset	Intel® C232
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	72 W
Processor cache type	Smart Cache
System bus rate	8 GT/s
Bus type	DMI3
ECC supported by processor	Yes
Embedded options available	No
Execute Disable Bit	Yes
Idle States	Yes
Maximum internal memory supported by processor	64 GB
Maximum number of PCI Express lanes	16
Memory bandwidth supported by processor (max)	37.5 GB/s
Memory clock speeds supported by processor	1866,2133 MHz
Memory types supported by processor	DDR3L, DDR4-SDRAM
PCI Express configurations	1x16, 1x8+2x4, 2x8
Processor codename	Kaby Lake
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor socket	LGA 1151 (Socket H4)
Processor threads	4
Scalability	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes
Conflict-Free processor	Yes

Specification	Value
Discrete graphics card	Yes
Discrete graphics card model	Aspeed AST2400

Specification	Value
Ethernet LAN	Yes
LAN controller	Intel® I210-AT

Specification	Value
Ethernet LAN (RJ-45) ports	3
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
PS/2 ports quantity	1
VGA (D-Sub) ports quantity	1

Specification	Value
PCI Express x16 (Gen 3.x) slots	1
PCI Express slots version	3.0

Specification	Value
Chassis type	Mini Tower

Specification	Value
Compatible operating systems	Windows Server 2012 R2 Windows Server 2016

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Enhanced Halt State	Yes
Intel Secure Key Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	No
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	97470

Specification	Value
Power supply	400 W

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 75%

Specification	Value
Number of 2.5" bays	2
Number of 3.5" bays	4
