7220 server 4 TB Desktop Intel Xeon Silver 4215 2.5 GHz 32 GB DDR4-SDRAM 1300 W
Model 7220Part no. 1100200EAN 4039407058105
58 specifications
- ProcessorIntel Xeon Silver
- Memory32 GB
- Storage4 TB
- Weight31 kg
- Processor manufacturerIntel
- Maximum storage capacity4000 TB
Overview
- Processor
- Intel Xeon Silver
- Memory
- 32 GB
- Storage
- 4 TB
- Weight
- 31 kg
- Processor manufacturer
- Intel
- Maximum storage capacity
- 4000 TB
- Brand
- TERRA
- Category
- Server
- Model
- 7220
- Part number
- 1100200
- EAN / UPC
- 4039407058105
- Also known as
- TERRA 7220 server 4 TB Desktop Intel Xeon Silver 4215 2.5 GHz 32 GB DDR4-SDRAM 1300 W
Specifications
58 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor model | 4215 |
| Processor frequency | 2.5 GHz |
| Processor boost frequency | 3.5 GHz |
| Processor cores | 8 |
| Processor cache | 11 MB |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 85 W |
| Embedded options available | Yes |
| Execute Disable Bit | Yes |
| Maximum internal memory supported by processor | 1 TB |
| Maximum number of PCI Express lanes | 48 |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Processor codename | Cascade Lake |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor package size | 76.0 x 56.5 mm |
| Processor socket | LGA 3647 (Socket P) |
| Processor threads | 16 |
| Scalability | 2S |
| Supported instruction sets | AVX-512 |
| Tcase | 77 °C |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 3 TB |
Storage
| Specification | Value |
|---|---|
| Maximum storage capacity | 4000 TB |
| Total storage capacity | 4 TB |
| Number of HDDs installed | 2 |
| HDD capacity | 2 TB |
| RAID support | Yes |
| Optical drive type | DVD±RW |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | Not available |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| VGA (D-Sub) ports quantity | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 3.0 |
Design
| Specification | Value |
|---|---|
| Chassis type | Desktop |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows Server 2019 Windows Server 2016 |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Processor ARK ID | 193389 |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Power supply | 1300 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 439 mm |
| Depth | 712 mm |
| Height | 8.9 mm |
| Weight | 31 kg |
