TERRA 1100559 server Tower (5U) Intel® Xeon® 3000 Sequence L3403
2 GHz 2 GB DDR3-SDRAM 550 W
Model 1100559
76 specifications
- ProcessorIntel® Xeon® 3000 Sequence
- Memory2 GB
- Processor manufacturerIntel
- HDD interfaceSerial ATA II
- Maximum graphics card memory4 MB
- Ethernet LANYes
Overview
- Processor
- Intel® Xeon® 3000 Sequence
- Memory
- 2 GB
- Processor manufacturer
- Intel
- HDD interface
- Serial ATA II
- Maximum graphics card memory
- 4 MB
- Ethernet LAN
- Yes
- Brand
- TERRA
- Category
- Server
- Model
- 1100559
- Part number
- 1100559
- Also known as
- TERRA 1100559 server Tower (5U) Intel® Xeon® 3000 Sequence L3403 2 GHz 2 GB DDR3-SDRAM 550 W
Specifications
76 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® 3000 Sequence |
| Processor model | L3403 |
| Processor frequency | 2 GHz |
| Processor cores | 2 |
| Processor cache | 4 MB |
| Motherboard chipset | Intel® 3420 |
| Memory channels supported by processor | Dual |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 30 W |
| Processor cache type | Smart Cache |
| System bus rate | 2.5 GT/s |
| Bus type | DMI |
| CPU multiplier (bus/core ratio) | 15 |
| ECC supported by processor | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Maximum internal memory supported by processor | 16.38 GB |
| Memory bandwidth supported by processor (max) | 17 GB/s |
| Memory clock speeds supported by processor | 1066 MHz |
| Memory types supported by processor | DDR3-SDRAM |
| Number of Processing Die Transistors | 382 M |
| PCI Express configurations | 1x16, 2x8 |
| Processing Die size | 81 mm² |
| Processor codename | Clarkdale |
| Processor lithography | 32 nm |
| Processor operating modes | 64-bit |
| Processor package size | 37.5 x 37.5 mm |
| Processor socket | LGA 1156 (Socket H) |
| Processor threads | 2 |
| Supported instruction sets | SSE4.2 |
| Thermal Monitoring Technologies | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
| Internal memory type | DDR3-SDRAM |
| ECC | Yes |
| Memory clock speed | 1333 MHz |
| Memory layout (slots x size) | 1 x 2 GB |
| Memory slots | 4 |
| Maximum internal memory | 16 GB |
Storage
| Specification | Value |
|---|---|
| HDD interface | Serial ATA II |
| HDD size | 3.5" |
| Number of HDDs supported | 8 |
| RAID support | Yes |
| Hot-swap | No |
| Internal drive bays | 4 x 3.5" |
| Optical drive type | DVD-RW |
Graphics
| Specification | Value |
|---|---|
| Maximum graphics card memory | 4 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Networking features | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x8 slots | 2 |
| PCI Express x16 slots | 1 |
| PCI Express slots version | 2.0 |
| PCI slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower (5U) |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows Server 2003 32/64 |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
Power
| Specification | Value |
|---|---|
| Power supply type | Fortron |
| Number of power supply units | 1 |
| Power requirements | 100-240 V, 10-5 A, 50-60 Hz |
| Power supply | 550 W |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, ISO9001 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 220 mm |
| Depth | 660 mm |
| Height | 425 mm |
Other features
| Specification | Value |
|---|---|
| Motherboard manufacturer | Intel |
