NEC Express5800 GT110b server Tower Intel® Xeon® 3000 Sequence X3430

2.4 GHz 1 GB DDR3-SDRAM

Model GT110bPart no. N8100-1594FEAN 4548835078550

116 specifications

ProcessorIntel® Xeon® 3000 Sequence
Memory1 GB
Weight11 kg
Processor manufacturerIntel
Maximum storage capacity8 TB
Maximum graphics card memory64 MB

See all specifications

Overview

Processor: Intel® Xeon® 3000 Sequence
Memory: 1 GB
Weight: 11 kg
Processor manufacturer: Intel
Maximum storage capacity: 8 TB
Maximum graphics card memory: 64 MB

Brand: NEC
Category: Server
Model: GT110b
Part number: N8100-1594F
EAN / UPC: 4548835078550
Also known as: NEC Express5800 GT110b server Tower Intel® Xeon® 3000 Sequence X3430 2.4 GHz 1 GB DDR3-SDRAM

Specifications

116 specifications in 16 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® 3000 Sequence
Processor model	X3430
Processor frequency	2.4 GHz
Processor boost frequency	2.8 GHz
Processor cores	4
Processor cache	8 MB
Motherboard chipset	Intel® 3420
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	95 W
Processor cache type	Smart Cache
System bus rate	2.5 GT/s
Bus type	DMI
CPU multiplier (bus/core ratio)	18
ECC supported by processor	Yes
Embedded options available	Yes
Execute Disable Bit	Yes
FSB Parity	No
Idle States	Yes
Maximum internal memory supported by processor	32 GB
Maximum number of PCI Express lanes	16
Memory bandwidth supported by processor (max)	21 GB/s
Memory clock speeds supported by processor	800,1066,1333 MHz
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
PCI Express configurations	1x16, 2x8, 4x4
Physical Address Extension (PAE)	36 bit
Processing Die size	296 mm²
Processor code	SLBLJ
Processor codename	Lynnfield
Processor lithography	45 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor threads	4
Stepping	B1
Supported instruction sets	SSE4.2
Tcase	72.7 °C
Thermal Monitoring Technologies	No
Conflict-Free processor	No

Memory

Specification	Value
Internal memory	1 GB
Internal memory type	DDR3-SDRAM
Memory clock speed	1333 MHz
Maximum internal memory	16 GB

Storage

Specification	Value
Maximum storage capacity	8 TB
Number of HDDs supported	4
RAID support	Yes
RAID levels	0, 1, 10
Drive device, transfer rate	3000 MB/s
Optical drive type	DVD-ROM

Graphics

Specification	Value
Maximum graphics card memory	64 MB

Network

Specification	Value
Wi-Fi	No
Bluetooth	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	10
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
DisplayPorts quantity	0
FireWire 800	No
Firewire (IEEE 1394) ports	0
Mini DisplayPorts quantity	0
PS/2 ports quantity	2
Parallel ports quantity	0
Serial ports quantity	1
VGA (D-Sub) ports quantity	1

Expansion slots

Specification	Value
PCI Express x4 slots	1
PCI Express x8 slots	1
PCI Express x16 slots	1
PCI Express slots version	2.0
PCI slots	1

Design

Specification	Value
Chassis type	Tower

Performance

Specification	Value
Performance management	ESMPRO V5

Software

Specification	Value
Compatible operating systems	Windows Server 2003 R2 / Server 2008/ Server 2008 R2 Standard (x64) Red Hat Linux

Processor special features

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	Yes
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	1.0
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	42927

Power

Specification	Value
Power consumption (typical)	128 W

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	20 - 80%
Relative humidity	20 - 80%

Weight & dimensions

Specification	Value
Width	175 mm
Depth	418 mm
Height	364 mm
Weight	11 kg

Packaging content

Specification	Value
Keyboard included	Yes

Other features

Specification	Value
Fibre Channel	No
Graphics card	Z9s
