NEC Express5800 120Rf-1, NL/FR/EN
Model Express5800 120Rf-1, NL/FR/ENPart no. E75NC7U-0002Z-90
32 specifications
- ProcessorIntel® Xeon®
- Memory0.5 GB
- Storage73 GB
- Weight15 kg
- Maximum graphics card memory16 MB
- Networking features2-ch. Gigabit Ethernet
Overview
- Processor
- Intel® Xeon®
- Memory
- 0.5 GB
- Storage
- 73 GB
- Weight
- 15 kg
- Maximum graphics card memory
- 16 MB
- Networking features
- 2-ch. Gigabit Ethernet
- Brand
- NEC
- Category
- Server
- Model
- Express5800 120Rf-1, NL/FR/EN
- Part number
- E75NC7U-0002Z-90
- Also known as
- NEC Express5800 120Rf-1, NL/FR/EN server Rack Intel® Xeon® 2.8 GHz 0.5 GB DDR2-SDRAM
Specifications
32 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® |
| Processor frequency | 2.8 GHz |
| Processor cache | 2 MB |
| Motherboard chipset | Intel® E7520 |
| Number of processors installed | 1 |
| Processor cache type | L2 |
| Processor front side bus | 800 MHz |
Memory
| Specification | Value |
|---|---|
| Internal memory | 0.5 GB |
| Internal memory type | DDR2-SDRAM |
| Memory slots | 8x DIMM |
Storage
| Specification | Value |
|---|---|
| HDD capacity | 73 GB |
| HDD interface | SCSI |
| Hot-swap | Yes |
Graphics
| Specification | Value |
|---|---|
| Maximum graphics card memory | 16 MB |
Network
| Specification | Value |
|---|---|
| Networking features | 2-ch. Gigabit Ethernet |
| Wake-on-LAN ready | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 4 |
| PS/2 ports quantity | 2 |
| Serial ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Expansion slots | 2x PCI 1x PCI-X 64bit/66MHz 1x PCI-X 64bit/133MHz |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack |
Software
| Specification | Value |
|---|---|
| Bundled software | ESMPRO Management Suite ExpressBuilder Configuration Software |
Power
| Specification | Value |
|---|---|
| Power supply type | HotSwap, PFC |
Certificates
| Specification | Value |
|---|---|
| Certification | UL, FCC, CE |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 483 mm |
| Depth | 835 mm |
| Height | 44 mm |
| Weight | 15 kg |
Other features
| Specification | Value |
|---|---|
| Security features | 2 Level Password |
| Power availability | 500 W |
