ThinkSystem SE350 server
960 GB Rack (1U) Intel® Xeon® D D-2163IT 2.1 GHz 64 GB DDR4-SDRAM
Model SE350Part no. 7D1XA01BEAEAN 5415247282143
48 specifications
- ProcessorIntel® Xeon® D
- Memory64 GB
- Storage960 GB
- Weight3.75 kg
- ColourBlack
- Processor manufacturerIntel
Overview
- Processor
- Intel® Xeon® D
- Memory
- 64 GB
- Storage
- 960 GB
- Weight
- 3.75 kg
- Colour
- Black
- Processor manufacturer
- Intel
- Brand
- Lenovo
- Category
- Server
- Model
- SE350
- Part numbers
- 7D1XA01BEA, 7D1XA019EA, 7D1XA017EA, 7D1XA016EA, 7D1XA01AEA, 7D1XA01CEA +12 more
- EAN / UPC
- 5415247282143, 8032976159422, 8032976159576, 5054444404073
- Also known as
- Lenovo ThinkSystem SE350 server 960 GB Rack (1U) Intel® Xeon® D D-2163IT 2.1 GHz 64 GB DDR4-SDRAM
Specifications
48 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® D |
| Processor model | D-2163IT |
| Processor frequency | 2.1 GHz |
| Processor boost frequency | 3 GHz |
| Processor cores | 12 |
| Processor cache | 17 MB |
| Number of processors installed | 1 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 64 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Memory clock speed | 2666 MHz |
| Memory layout (slots x size) | 1 x 64 GB |
| Maximum internal memory | 256 GB |
Storage
| Specification | Value |
|---|---|
| Maximum storage capacity | 15.68 TB |
| Total storage capacity | 960 GB |
| Number of SSDs installed | 2 |
| SSD capacity | 480 GB |
| SSD interface | M.2 |
| Number of SSDs supported | 4 |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Optical drive type | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Matrox G200 |
Network
| Specification | Value |
|---|---|
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet, Gigabit Ethernet |
| Wake-on-LAN ready | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Serial ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Performance management | XClarity |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi. Ubuntu Server certification. |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Number of redundant power supplies supported | 2 |
| Number of main power supplies | 2 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 209 mm |
| Depth | 376 mm |
| Height | 43 mm |
| Weight | 3.75 kg |
