HP DL360 Gen9 E5-2630v4 1P 16GB-R P440ar 8SFF 500W PS SAS

Model DL360 Gen9 E5-2630v4 1P 16GB-R P440ar 8SFF 500W PS SASPart no. 818208-B21 BB-NEW OPEN BOX

93 specifications

Overview

Brand: HP
Category: Server
Model: DL360 Gen9 E5-2630v4 1P 16GB-R P440ar 8SFF 500W PS SAS
Part number: 818208-B21 BB-NEW OPEN BOX
Also known as: HP ProLiant DL360 Gen9 E5-2630v4 1P 16GB-R P440ar 8SFF 500W PS SAS server 0 GB Blade Intel® Xeon® E5 v4 2.2 GHz DDR4-SDRAM

93 specifications in 12 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E5 v4
Processor model	E5-2630V4
Processor frequency	2.2 GHz
Processor boost frequency	3.1 GHz
Processor cores	10
Processor cache	25 MB
Memory channels supported by processor	Quad
Number of processors installed	1
Thermal Design Power (TDP)	85 W
Processor cache type	Smart Cache
System bus rate	8 GT/s
Bus type	QPI
ECC supported by processor	Yes
Embedded options available	No
Execute Disable Bit	Yes
Idle States	Yes
Maximum internal memory supported by processor	1.53 TB
Maximum number of PCI Express lanes	40
Memory bandwidth supported by processor (max)	68.3 GB/s
Memory clock speeds supported by processor	1600,1866,2133 MHz
Memory types supported by processor	DDR4-SDRAM
Number of QPI links	2
Physical Address Extension (PAE)	46 bit
Physical Address Extension (PAE)	Yes
Processor code	SR2R7
Processor codename	Broadwell
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	45 x 52.5 mm
Processor series	Intel Xeon E5-2600 v4
Processor socket	LGA 2011-v3
Processor threads	20
Scalability	2S
Stepping	R0
Supported instruction sets	AVX 2.0
Tcase	74 °C
Thermal Monitoring Technologies	Yes
Conflict-Free processor	Yes

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Serial ports quantity	1
VGA (D-Sub) ports quantity	1

Specification	Value
PCI Express slots version	3.0

Specification	Value
Chassis type	Blade
Rack mounting	Yes

Specification	Value
Operating system installed	No
Compatible operating systems	Microsoft Windows Server Canonical Ubuntu Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Solaris VMware Citrix XenServer

Specification	Value
CPU configuration (max)	2
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	No
Intel Identity Protection Technology version	0.00
Intel Secure Key Technology version	1.00
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	92981

Specification	Value
Redundant power supply (RPS) support	Yes
Power supply	500 W
Number of main power supplies	1

Specification	Value
Sustainability certificates	ENERGY STAR
