TX2550 M7
Model TX2550 M7Part no. VFY:T2557SC320IN-XEAN 4065221975243
40 specifications
- ProcessorIntel Xeon Silver
- Memory16 GB
- OSNo
- Weight41.9 kg
- ColourBlack, Red
- Processor manufacturerIntel
Overview
- Processor
- Intel Xeon Silver
- Memory
- 16 GB
- OS
- No
- Weight
- 41.9 kg
- Colour
- Black, Red
- Processor manufacturer
- Intel
- Brand
- Fujitsu
- Category
- Server
- Model
- TX2550 M7
- Part numbers
- VFY:T2557SC320IN-X, VFY:T2557SC350IN-X, VFY:T2557SC310IN-X, VFY:T2557SC351IN, VFY:T2557SC351IN-X, VFY:T2557SC030PL +20 more
- EAN / UPC
- 4065221975243, 4065221976707, 4065221975281, 4065221976714 +13 more
- Also known as
- Fujitsu PRIMERGY TX2550 M7 server Tower Intel Xeon Silver 4410Y 2 GHz 16 GB DDR5-SDRAM 900 W
Specifications
40 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Processor model | 4410Y |
| Processor frequency | 2 GHz |
| Processor boost frequency | 3.9 GHz |
| Processor cores | 12 |
| Processor cache | 30 MB |
| Number of processors installed | 1 |
| Configurable TDP-down | 4.5 W |
| Bus type | OPI |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory slots | 16x DIMM |
| Maximum internal memory | 4 TB |
Storage
| Specification | Value |
|---|---|
| RAID support | Yes |
| Optical drive type | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x8 (Gen 4.x) slots | 8 |
| PCI Express x16 (Gen 4.x) slots | 4 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black, Red |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Windows Server 2022 Datacenter Windows Server 2022 Standard Windows Server 2019 Datacenter Windows Server 2019 Standard Windows Server 2019 Essentials SUSE Linux Enterprise Server 15 Red Hat Enterprise Linux 8 |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Intel Secure Key Technology version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel TSX-NI version | 0.00 |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Power supply | 900 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 8 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 41.9 kg |
