Fujitsu TX2540 M1 +S26361-F2567-D423

Model TX2540 M1 +S26361-F2567-D423Part no. VFY:T2541SX310FR/KIT

104 specifications

Overview

Brand: Fujitsu
Category: Server
Model: TX2540 M1 +S26361-F2567-D423
Part numbers: VFY:T2541SX310FR/KIT, VFY:T2541SC270IN/KIT, VFY:T2541SX300FR/KIT
Also known as: Fujitsu PRIMERGY TX2540 M1 +S26361-F2567-D423 server 0 GB Tower Intel® Xeon® E5 V2 Family E5-2430V2 2.5 GHz 16 GB DDR3-SDRAM 450 W Windows Server 2012 R2 Standa

104 specifications in 13 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E5 V2 Family
Processor model	E5-2430V2
Processor frequency	2.5 GHz
Processor boost frequency	3 GHz
Processor cores	6
Processor cache	15 MB
Motherboard chipset	Intel® C602
Memory channels supported by processor	Triple
Number of processors installed	1
Thermal Design Power (TDP)	80 W
Processor cache type	Smart Cache
System bus rate	7.2 GT/s
Bus type	QPI
ECC supported by processor	Yes
Embedded options available	Yes
Execute Disable Bit	Yes
Idle States	Yes
Maximum internal memory supported by processor	384 GB
Maximum number of PCI Express lanes	24
Memory bandwidth supported by processor (max)	38.4 GB/s
Memory clock speeds supported by processor	800,1066,1333,1600 MHz
Memory types supported by processor	DDR3-SDRAM
Number of QPI links	1
PCI Express configurations	x4, x8, x16
Physical Address Extension (PAE)	46 bit
Physical Address Extension (PAE)	Yes
Processor code	SR1AH
Processor codename	Ivy Bridge EN
Processor lithography	22 nm
Processor operating modes	64-bit
Processor package size	45 x 42.5 mm
Processor series	Intel Xeon E5-2400 v2
Processor socket	LGA 1356 (Socket B2)
Processor threads	12
Scalability	2S
Stepping	S1
Supported instruction sets	AVX
Tcase	76 °C
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Specification	Value
Total storage capacity	0 GB
Number of HDDs installed	0
HDD interface	Serial ATA III, Serial Attached SCSI (SAS)
HDD size	2.5"
Number of HDDs supported	24
Optical drive type	DVD Super Multi
Supported storage drive interfaces	SAS, Serial ATA III

Specification	Value
Chassis type	Tower

Specification	Value
Operating system installed	Windows Server 2012 R2 Standard
Compatible operating systems	Windows Server 2012 R2 / 2012/ 2008 R2/ Datacenter, Windows Server 2012 R2 / 2012/ 2008 R2/ Standard, Windows Server 2012 R2 / 2012/ 2008 R2/ Essentials, Windows Server 2012 R2 / 2012/ 2008 R2/ Foundation, VMware vSphere 6.0, 5.5, 5.1, SUSE Linux Enterprise Server 12,11 Red Hat Enterprise Linux 7, 6

Specification	Value
CPU configuration (max)	2
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	No
Intel Identity Protection Technology version	0.00
Intel Secure Key Technology version	1.00
Intel TSX-NI	No
Intel TSX-NI version	0.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	75785

Specification	Value
Redundant power supply (RPS) support	Yes
Power supply	450 W
Number of redundant power supplies supported	2
Number of main power supplies	1
Power supply input frequency	50 - 60 Hz

Specification	Value
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 85%

Specification	Value
Certification	CB, RoHS, WEEE
