TX1330 M6
Model TX1330 M6Part no. VFY:T1336SC042INEAN 4066733133428
38 specifications
- ProcessorIntel Xeon E
- Memory32 GB
- Storage0 GB
- OSNo
- Weight28.8 kg
- ColourBlack, Red
Overview
- Processor
- Intel Xeon E
- Memory
- 32 GB
- Storage
- 0 GB
- OS
- No
- Weight
- 28.8 kg
- Colour
- Black, Red
- Brand
- Fujitsu
- Category
- Server
- Model
- TX1330 M6
- Part numbers
- VFY:T1336SC042IN, SAG:TX1330M6-C12T, SAG:TX1330M6-HMST, SAG:TX1330M6-MXT, VFY:T1336SX263PL, VFY:T1336SX265PL +4 more
- EAN / UPC
- 4066733133428, 4066733142246, 4066733149320
- Also known as
- Fujitsu PRIMERGY TX1330 M6 server 0 GB Tower Intel Xeon E E-2488 3.2 GHz 32 GB DDR5-SDRAM 500 W
Specifications
38 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2488 |
| Processor frequency | 3.2 GHz |
| Processor boost frequency | 5.6 GHz |
| Performance cores | 8 |
| Processor cores | 8 |
| Processor cache | 24 MB |
| Motherboard chipset | Intel C266 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 4800 MHz |
| Memory slots | 4x DIMM |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 0 GB |
| HDD interface | SATA III, Serial Attached SCSI (SAS) |
| Number of HDDs supported | 8 |
| Supported HDD sizes | 2.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 10 |
| Optical drive type | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Intel I210 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 7 |
| VGA (D-Sub) ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black, Red |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
Power
| Specification | Value |
|---|---|
| Power supply | 500 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 8 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 551 mm |
| Depth | 448 mm |
| Height | 457 mm |
| Weight | 28.8 kg |
