Fujitsu TX1330 M3
Model TX1330 M3Part no. VFY:T1333SX260ITEAN 4057185856331
76 specifications
- ProcessorIntel® Xeon® E3 v6
- Memory8 GB
- Processor manufacturerIntel
- Number of HDDs installed0
- Ethernet LANYes
- Ethernet LAN (RJ-45) ports2
Overview
- Processor
- Intel® Xeon® E3 v6
- Memory
- 8 GB
- Processor manufacturer
- Intel
- Number of HDDs installed
- 0
- Ethernet LAN
- Yes
- Ethernet LAN (RJ-45) ports
- 2
- Brand
- Fujitsu
- Category
- Server
- Model
- TX1330 M3
- Part numbers
- VFY:T1333SX260IT, VFY:T1333SX240IT, VFY:T1333SX230IT, VFY:T1333SX250IT, VFY:T1333SX270IT, VFY:T1333SX280IT +34 more
- EAN / UPC
- 4057185856331, 4058154207383, 4057185857581, 4057185857604 +28 more
- Also known as
- Fujitsu PRIMERGY TX1330 M3 server Intel® Xeon® E3 v6 E3-1220 v6 3 GHz 8 GB DDR4-SDRAM
Specifications
76 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E3 v6 |
| Processor model | E3-1220 v6 |
| Processor frequency | 3 GHz |
| Processor boost frequency | 3.5 GHz |
| Processor cores | 4 |
| Processor cache | 8 MB |
| Motherboard chipset | Intel® C236 |
| Memory channels supported by processor | Dual |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 72 W |
| Configurable TDP-down | 72 W |
| Processor cache type | Smart Cache |
| System bus rate | 8 GT/s |
| Bus type | DMI3 |
| ECC supported by processor | Yes |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Maximum internal memory supported by processor | 64 GB |
| Maximum number of PCI Express lanes | 16 |
| Memory bandwidth supported by processor (max) | 37.5 GB/s |
| Memory clock speeds supported by processor | 1866,2133 MHz |
| Memory types supported by processor | DDR3L, DDR4-SDRAM |
| PCI Express configurations | 1x16, 1x8+2x4, 2x8 |
| Processor codename | Kaby Lake |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor package size | 37.5 x 37.5 mm |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 4 |
| Scalability | 1S |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Thermal Monitoring Technologies | Yes |
| Conflict-Free processor | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2400 MHz |
| Memory layout (slots x size) | 1 x 8 GB |
| Memory slots | 4 |
| Maximum internal memory | 64 GB |
Storage
| Specification | Value |
|---|---|
| Number of HDDs installed | 0 |
| Optical drive type | DVD Super Multi |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 3.0 |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® OS Guard | Yes |
| Intel® Quick Sync Video Technology | No |
| Intel® Secure Key | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Processor ARK ID | 97470 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 177 mm |
| Depth | 560 mm |
| Height | 455 mm |
