TX1320 M5
Model TX1320 M5Part no. VFY:T1325SC021INEAN 4065221880165
51 specifications
- ProcessorIntel Xeon E
- Memory16 GB
- Storage0 GB
- OSNo
- Weight11.1 kg
- ColourBlack
Overview
- Processor
- Intel Xeon E
- Memory
- 16 GB
- Storage
- 0 GB
- OS
- No
- Weight
- 11.1 kg
- Colour
- Black
- Brand
- Fujitsu
- Category
- Server
- Model
- TX1320 M5
- Part numbers
- VFY:T1325SC021IN, LKN:T1325S0003IN, VFY:T1325SC051IN, VFY:T1325SC020AU, VFY:T1325SC010AU, LKN:T1325S0002PL +4 more
- EAN / UPC
- 4065221880165, 4065221895824, 4065221880196, 4065221880189 +2 more
- Also known as
- Fujitsu PRIMERGY TX1320 M5 server 0 GB Tower Intel Xeon E E-2378 2.6 GHz 16 GB DDR4-SDRAM 500 W
Specifications
51 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2378 |
| Processor frequency | 2.6 GHz |
| Processor boost frequency | 4.8 GHz |
| Processor cache | 16 MB |
| Motherboard chipset | Intel C256 |
| Number of processors installed | 1 |
| Execute Disable Bit | Yes |
| Idle States | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Maximum internal memory | 128 GB |
Storage
| Specification | Value |
|---|---|
| Maximum storage capacity | 0 TB |
| Total storage capacity | 0 GB |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6 |
| Optical drive type | DVD-RW |
Network
| Specification | Value |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Intel I210 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 4 |
| DisplayPorts quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 (Gen 3.x) slots | 2 |
| PCI Express x8 (Gen 4.x) slots | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black |
| Motherboard form factor | UCFF |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Windows Server 2022 Datacenter Windows Server 2022 Standard Windows Server 2022 Essentials Windows Server 2019 Datacenter Windows Server 2019 Standard Windows Server 2019 Essentials |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 500 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 98 mm |
| Depth | 400 mm |
| Height | 340 mm |
| Weight | 11.1 kg |
