Fujitsu TX1320 M3
Model TX1320 M3Part no. PRJ:T1323S0001ESEAN 4059595582404
40 specifications
- ProcessorIntel® Xeon® E3 v6
- Memory16 GB
- Storage1.8 TB
- Weight10 kg
- Cabling technology10/100/1000Base-T(X)
- Ethernet LAN (RJ-45) ports2
Overview
- Processor
- Intel® Xeon® E3 v6
- Memory
- 16 GB
- Storage
- 1.8 TB
- Weight
- 10 kg
- Cabling technology
- 10/100/1000Base-T(X)
- Ethernet LAN (RJ-45) ports
- 2
- Brand
- Fujitsu
- Category
- Server
- Model
- TX1320 M3
- Part numbers
- PRJ:T1323S0001ES, LKN:T1323S0003PL, VFY:T1323SX120IT, VFY:T1323SX130IT, VFY:T1323SX140IT, LKN:T1323S0005PL +26 more
- EAN / UPC
- 4059595582404, 4059595582411, 4059595582756, 4057185865296 +13 more
- Also known as
- Fujitsu PRIMERGY TX1320 M3 server 1.8 TB Tower Intel® Xeon® E3 v6 E3-1230V6 3.5 GHz 16 GB DDR4-SDRAM
Specifications
40 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® E3 v6 |
| Processor model | E3-1230V6 |
| Processor frequency | 3.5 GHz |
| Processor cores | 4 |
| Motherboard chipset | Intel® C236 |
| Number of processors installed | 1 |
| Intelligent Platform Management Interface (IPMI) support | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Memory clock speed | 2400 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4 |
| Maximum internal memory | 64 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 1.8 TB |
| Number of HDDs installed | 3 |
| HDD capacity | 600 GB |
Network
| Specification | Value |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Intel I210 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Serial ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 (Gen 3.x) slots | 1 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| PCI Express x8 (Gen 3.x) slots | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Microsoft Hyper-V Server 2012 R2 Microsoft Hyper-V Server 2016 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2016 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Server 20 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 231 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 98 mm |
| Depth | 399 mm |
| Height | 340 mm |
| Weight | 10 kg |
Other features
| Specification | Value |
|---|---|
| Power management | Yes |
