Fujitsu TX100 S3p + Windows Server 2012 Foundation, 1 CPU, ROK

Model TX100 S3p + Windows Server 2012 Foundation, 1 CPU, ROKPart no. VFY:T1003SC120IN + S26361-F2567-D440

122 specifications

ProcessorIntel® Xeon® E3 V2 Family
Memory2 GB
Storage250 GB
Noise24 dB
OSNo
Weight14 kg

See all specifications

Overview

Processor: Intel® Xeon® E3 V2 Family
Memory: 2 GB
Storage: 250 GB
Noise: 24 dB
OS: No
Weight: 14 kg

Brand: Fujitsu
Category: Server
Model: TX100 S3p + Windows Server 2012 Foundation, 1 CPU, ROK
Part number: VFY:T1003SC120IN + S26361-F2567-D440
Also known as: Fujitsu PRIMERGY TX100 S3p + Windows 2012 Foundation, 1 CPU, ROK server 250 GB Tower Intel® Xeon® E3 V2 Family E3-1220V2 3.1 GHz 2 GB DDR3-SDRAM 250 W

Specifications

122 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 V2 Family
Processor model	E3-1220V2
Processor frequency	3.1 GHz
Processor boost frequency	3.5 GHz
Processor cores	4
Processor cache	8 MB
Motherboard chipset	Intel® C202
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	69 W
Processor cache type	Smart Cache
System bus rate	5 GT/s
Bus type	DMI
CPU multiplier (bus/core ratio)	31
ECC supported by processor	Yes
Embedded options available	No
Execute Disable Bit	Yes
FSB Parity	No
Idle States	Yes
Maximum internal memory supported by processor	32 GB
Maximum number of SMP processors	1
Memory bandwidth supported by processor (max)	25.6 GB/s
Memory clock speeds supported by processor	1333,1600 MHz
Memory types supported by processor	DDR3-SDRAM
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Processor code	SR0PH
Processor codename	Ivy Bridge
Processor lithography	22 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Stepping	E1
Supported instruction sets	AVX, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Memory

Specification	Value
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
ECC	Yes
Maximum internal memory	32768 MB
Memory clock speed	1600 MHz
Memory layout (slots x size)	1 x 2 GB
Memory slots	4
Maximum internal memory	32 GB

Storage

Specification	Value
Maximum storage capacity	12 TB
Total storage capacity	250 GB
Number of HDDs installed	1
HDD capacity	250 GB
HDD interface	Serial ATA III
HDD speed	7200 RPM
HDD size	3.5"
Number of HDDs supported	4
RAID support	Yes
RAID levels	0, 1, 10
Hot-swap	No
Optical drive type	DVD Super Multi

Graphics

Specification	Value
On-board graphics card model	Not available
Maximum graphics card memory	64 MB

Network

Specification	Value
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN	Yes
LAN controller	Intel® 82574L, Intel® 82579LM

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	9
PS/2 ports quantity	0
Serial ports quantity	1
VGA (D-Sub) ports quantity	1

Expansion slots

Specification	Value
PCI Express x1 slots	1
PCI Express x4 slots	1
PCI Express x8 slots	2
PCI Express slots version	3.0

Design

Specification	Value
Chassis type	Tower

Performance

Specification	Value
Noise level	24 dB

Software

Specification	Value
Operating system installed	No
Compatible operating systems	Windows Hyper-V Server 2012 Windows Server 2012 Datacenter Windows Server 2012 Standard Windows Server 2012 Essentials Windows Server 2012 Foundation Windows Storage Server 2012 Standard Windows Hyper-V Server 2008 R2 Windows Server 2008 R2 Datacenter Windows Server 2008 R2 Enterprise Windows Server

Processor special features

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	Yes
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Identity Protection Technology version	1.00
Intel Rapid Storage Technology	No
Intel TSX-NI	No
Intel TSX-NI version	0.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	65734

Power

Specification	Value
Redundant power supply (RPS) support	No
Power supply	250 W
Number of main power supplies	1
Power supply input frequency	47/63 Hz
Power consumption (typical)	209 W

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C

Certificates

Specification	Value
Certification	GS, CE, CSA, ULc/us, FCC, CB, RoHS, WEEE, VCCI, KC, CCC, C-Tick

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	175 mm
Depth	419 mm
Height	395 mm
Weight	14 kg

Other features

Specification	Value
Graphics card	ES1000
Graphics card family	ATI
