Fujitsu TX100 S2 + Windows Server 2008 R2 Standard ROK (SP1)

Model TX100 S2 + Windows Server 2008 R2 Standard ROK (SP1)Part no. VFY:T1002SH010IN S26361-F2567-L311

123 specifications

ProcessorIntel® Xeon® 3000 Sequence
Memory4 GB
Storage2 TB
Noise24 dB
Weight12 kg
Processor manufacturerIntel

See all specifications

Overview

Processor: Intel® Xeon® 3000 Sequence
Memory: 4 GB
Storage: 2 TB
Noise: 24 dB
Weight: 12 kg
Processor manufacturer: Intel

Brand: Fujitsu
Category: Server
Model: TX100 S2 + Windows Server 2008 R2 Standard ROK (SP1)
Part number: VFY:T1002SH010IN S26361-F2567-L311
Also known as: Fujitsu PRIMERGY TX100 S2 + Windows 2008 R2 Standard ROK (SP1) server 2 TB Tower Intel® Xeon® 3000 Sequence X3430 2.4 GHz 4 GB DDR3-SDRAM 250 W

Specifications

123 specifications in 17 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® 3000 Sequence
Processor model	X3430
Processor frequency	2.4 GHz
Processor boost frequency	2.8 GHz
Processor cores	4
Processor cache	8 MB
Motherboard chipset	Intel® 3420
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	95 W
Processor cache type	Smart Cache
System bus rate	2.5 GT/s
Bus type	DMI
CPU multiplier (bus/core ratio)	18
Compatible processor series	Intel® Celeron®, Intel® Pentium® Dual-Core
ECC supported by processor	Yes
Embedded options available	Yes
Execute Disable Bit	Yes
FSB Parity	No
Idle States	Yes
Maximum internal memory supported by processor	32 GB
Maximum number of PCI Express lanes	16
Memory bandwidth supported by processor (max)	21 GB/s
Memory clock speeds supported by processor	800,1066,1333 MHz
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	774 M
PCI Express configurations	1x16, 2x8, 4x4
Physical Address Extension (PAE)	36 bit
Processing Die size	296 mm²
Processor code	SLBLJ
Processor codename	Lynnfield
Processor lithography	45 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Xeon 3400 Series
Processor socket	LGA 1156 (Socket H)
Processor threads	4
Stepping	B1
Supported instruction sets	SSE4.2
Tcase	72.7 °C
Thermal Monitoring Technologies	No
Conflict-Free processor	No

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
ECC	Yes
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 2 GB
Memory slots	4x DIMM
Maximum internal memory	16 GB

Storage

Specification	Value
Total storage capacity	2 TB
Number of HDDs installed	2
HDD capacity	1 TB
HDD interface	Serial ATA
HDD size	3.5"
Number of HDDs supported	4
RAID support	Yes
Hot-swap	Yes
Optical drive type	DVD-RW

Graphics

Specification	Value
Maximum graphics card memory	64 MB

Network

Specification	Value
Network ready	Yes
Ethernet LAN	Yes
LAN controller	Intel® 82578DM
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	11
PS/2 ports quantity	0
Serial ports quantity	1
VGA (D-Sub) ports quantity	1

Expansion slots

Specification	Value
PCI Express x4 slots	1
PCI Express x8 slots	2
PCI Express slots version	2.0
PCI slots	1

Design

Specification	Value
Chassis type	Tower

Performance

Specification	Value
Noise level	24 dB

Software

Specification	Value
Compatible operating systems	Windows Server 2008/Server 2003/Small Business Server 2011 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux

Processor special features

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	Yes
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	No
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Turbo Boost Technology	1.0
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	42927

Power

Specification	Value
Redundant power supply (RPS) support	No
Number of power supply units	1
Power requirements	100 - 240V
Power supply	250 W
Power supply input frequency	47 - 63 Hz
Power consumption (typical)	171 W

Operational conditions

Specification	Value
Operating temperature (T-T)	10 - 35 °C

Certificates

Specification	Value
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Certification	GS, CE, CSAc/us, ULc/us, FCC, CB, RoHS, WEEE

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	203 mm
Depth	386 mm
Height	390 mm
Weight	12 kg

Other features

Specification	Value
Data transfer rate	1 Gbit/s
Dimensions (WxDxH)	203 x 386 x 390 mm
Graphics card	ES1000
Graphics card family	ATI
Mac compatibility	No
Supported data transfer rates	10/100/1000 Mbit/s
