Fujitsu PRIMERGY S6R server Tower Intel® Xeon® 6000 Sequence E6520
4 GB DDR3-SDRAM 800 W
Model S6RPart no. LKN:T2006S0278FR
30 specifications
- ProcessorIntel® Xeon® 6000 Sequence
- Memory4 GB
- RAID supportYes
- Cabling technology10/100/1000Base-T(X)
- Ethernet LAN (RJ-45) ports2
- PCI Express x4 slots3
Overview
- Processor
- Intel® Xeon® 6000 Sequence
- Memory
- 4 GB
- RAID support
- Yes
- Cabling technology
- 10/100/1000Base-T(X)
- Ethernet LAN (RJ-45) ports
- 2
- PCI Express x4 slots
- 3
- Brand
- Fujitsu
- Category
- Server
- Model
- S6R
- Part number
- LKN:T2006S0278FR
- Also known as
- Fujitsu PRIMERGY S6R server Tower Intel® Xeon® 6000 Sequence E6520 4 GB DDR3-SDRAM 800 W
Specifications
30 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 6000 Sequence |
| Processor model | E6520 |
| Motherboard chipset | Intel® 5500 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR3-SDRAM |
| Memory clock speed | 1333 MHz |
| Memory slots | 12x DIMM |
| Maximum internal memory | 96 GB |
Storage
| Specification | Value |
|---|---|
| RAID support | Yes |
| RAID levels | 0, 1, 5, 6, 10, 50, 60, 1E |
| Optical drive type | DVD-RW |
Network
| Specification | Value |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Wake-on-LAN ready | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 10 |
| PS/2 ports quantity | 0 |
| Serial ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 slots | 3 |
| PCI Express x8 slots | 2 |
| PCI Express slots version | 2.0 |
| PCI slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Microsoft Hyper-V Server 2012 Microsoft Windows Server 2012 Datacenter Microsoft Windows Server 2012 Standard Microsoft Hyper-V Server 2008 R2 Microsoft Windows Server 2008 R2 Datacenter Microsoft Windows Server 2008 R2 Enterprise Microsoft Windows Server 2008 R2 Standard Microsoft Windows Web Serve |
Power
| Specification | Value |
|---|---|
| Power supply | 800 W |
| Power supply input frequency | 47 - 63 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Certificates
| Specification | Value |
|---|---|
| Certification | TUV, CE, CSA, WEEE, VCCI, RoHS, BSMI, FCC, ULc/US |
